2. 3*1 or 3*1.5mm cable for option
3.
Seald silicone endcaps
- Product Details
- {{item.text}}
Quick Details
-
Color Temperature(CCT):
-
3000-6500K, Cool White Warm White natural white
-
Input Voltage(V):
-
AC85-265V
-
CRI (Ra>):
-
83
-
Working Temperature(℃):
-
-25 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HonLight
-
Model Number:
-
HNX-TP65-100W8F-H
-
Lamp name:
-
140lmw triproof light
-
CCT option:
-
2700K-6500K
-
Material:
-
6063 Aluminum Alloy+PC
-
Cover option:
-
Clear PC Cover, Frosted PC Cover
-
Power factor:
-
0.95
-
Usage:
-
Industry warehouse
-
Driver:
-
isolated internal Driver
-
Beam angle:
-
120 Degree
-
Lamp Luminous Flux(lm):
-
100-110lm/w 130-140lm/w
Quick Details
-
Warranty(Years):
-
5
-
Lamp Luminous Efficiency(lm/w):
-
140
-
Lamp Body Material:
-
Aluminum Alloy
-
Color Temperature(CCT):
-
3000-6500K, Cool White Warm White natural white
-
Input Voltage(V):
-
AC85-265V
-
CRI (Ra>):
-
83
-
Working Temperature(℃):
-
-25 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HonLight
-
Model Number:
-
HNX-TP65-100W8F-H
-
Lamp name:
-
140lmw triproof light
-
CCT option:
-
2700K-6500K
-
Material:
-
6063 Aluminum Alloy+PC
-
Cover option:
-
Clear PC Cover, Frosted PC Cover
-
Power factor:
-
0.95
-
Usage:
-
Industry warehouse
-
Driver:
-
isolated internal Driver
-
Beam angle:
-
120 Degree
-
Lamp Luminous Flux(lm):
-
100-110lm/w 130-140lm/w
Product Description
Feature:
1. Tri-proof led fixture for waterproof, dust, corrosion and pressure-proof, IP65, IP66, IK10
2. Rated AC Input voltage AC100-277V, widely work for AC90-265V; Safety operating voltage DC30~DC42V
3. Constant LED forwarder current 45~50mA during tube operating;(Best design for low LED light decay & long life time)
4. Patent design tool for Aluminum housing, PC diffuser and Aluminum PCB board
5. Temperature difference less than 20°C between inside and outside; Excellent heat dissipation depending on whole thick aluminum housing
6. Widely use for ambient lighting application
7. No UV ,No lead, No Mercury
8. Being reduced 40% heat dissipation, compared with traditional fluorescent lamp
2. Rated AC Input voltage AC100-277V, widely work for AC90-265V; Safety operating voltage DC30~DC42V
3. Constant LED forwarder current 45~50mA during tube operating;(Best design for low LED light decay & long life time)
4. Patent design tool for Aluminum housing, PC diffuser and Aluminum PCB board
5. Temperature difference less than 20°C between inside and outside; Excellent heat dissipation depending on whole thick aluminum housing
6. Widely use for ambient lighting application
7. No UV ,No lead, No Mercury
8. Being reduced 40% heat dissipation, compared with traditional fluorescent lamp
Project case
Enduro Series Triproof widely used for car parking, railway station, car washing shop, factory workshop etc.
Detailed Images
Male-femail connector for linkable
3 pin connector for linkable
Emergency 1hrs, 1.5hrs, 2hrs, 3hrs
IKIP66 IK10
1. Aluminum housing with frosted pc cover
D shap design
1. High Efficacy LED
2. Inner aluminum PCB board
Linkable
1. Self-wiring, wire-insert connector(3pin only)
2. 110lm/w or 140lm/w
Endruo Series
1. Optional Function: DALI Dimmable, 1-10V Dimmable, Microwave Motion Sensor, Emergency
2. Fit for 3-8m install height
Product Presentation
|
Product Name
|
Enduro Series(TP65)
|
|
Material
|
Aluminum housing+pc cover+inner aluminum pcb board
|
|
Power
|
20w, 40w,60w
|
|
Voltage
|
AC200-240V or AC100-277V
|
|
CCT
|
2700-6500k
|
|
Length
|
0.6m 1.2m 1.5m 1.8m 2.4m
|
|
Lumen
|
100-110lm/w or 120-130lm/w
|
|
Warranty
|
5 Years warranty
|
|
Certificate
|
ETL, CE, ROHS
|
Certificate
Related Products
Packing&Shipping
|
Length
|
Carton Size
|
Per Carton
|
Gross Weight
|
|
0.6m
|
70*24*31cm
|
6pcs/Carton
|
10.0KG
|
|
1.2m
|
130*24*31cm
|
6pcs/Carton
|
16.5KG
|
|
1.5m
|
160*24*31cm
|
6pcs/Carton
|
20.0KG
|
