Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
STAR CHINA MOTOR
-
Model Number:
-
380SA-5030
-
Torque:
-
1.31~25 kg.cm
-
Application:
-
Wheelchair
-
Keywords:
-
High Speed High Torque Dc Motor
-
Feature:
-
Dual output shaft
-
Rated Voltage:
-
DC: 7.4V
-
Certification:
-
ISO9001/ISO14001/ISO13485/IATF16949
-
Brush Type:
-
Electric Brush
-
Noise:
-
Low noise
-
no load speed:
-
23000±12%rpm
-
no load current:
-
≤1.5A
-
Starting voltage:
-
DC:1.5V max
Quick Details
-
Speed(RPM):
-
custom
-
Continuous Current(A):
-
13A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
STAR CHINA MOTOR
-
Model Number:
-
380SA-5030
-
Torque:
-
1.31~25 kg.cm
-
Application:
-
Wheelchair
-
Keywords:
-
High Speed High Torque Dc Motor
-
Feature:
-
Dual output shaft
-
Rated Voltage:
-
DC: 7.4V
-
Certification:
-
ISO9001/ISO14001/ISO13485/IATF16949
-
Brush Type:
-
Electric Brush
-
Noise:
-
Low noise
-
no load speed:
-
23000±12%rpm
-
no load current:
-
≤1.5A
-
Starting voltage:
-
DC:1.5V max
Products Description
|
Testing voltage
|
DC: 7.4V
|
|
Load
|
100g.cm
|
|
Load current
|
≤6.5A
|
|
Load speed
|
20000±12%rpm
|
|
Stall torque
|
900g.cm min
|
|
Stall current
|
55A max
|
|
Motor outer diameter
|
φ27.8max
|
|
Motor height
|
38.1±0.3
|
|
Shaft outer diameter
|
φ2.3+0/-0.005
|
|
Terminal height
|
6.0±0.3mm
|
|
Shaft extension
|
7.5±0.5mm
|
|
Axial clearance
|
0.05~0.20mm
|
Features :
1.
Pure copper coil small internal resistance, stable current, low heat
2.
Oxygen free copper commutator Smaller contact resistance reduces commutation spark More wear resistant, longer life
3.
Strontium titanate ring varistor Absorb spark, reduce electromagnetic interference, reduce electromagnetic noise
4.
Thickened carbon brush, more resistant to wear Small internal resistance, better conductivity Small commutation spark, longer life
5.
Strong magnetic magnetic tile The magnetic field density is high, The magnetic force is stronger
Product Application
More application :
Smart home appliances,models, power tools, communication equipment, medical devices, health care equipment, toys and fitness equipment and other products.
