1/2.8" IMX335 Low light CMOS sensor
Max. 5MP resolution 2592 x 1944 output
low illumination 0.1Lux
Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
RTSP and 0nvif 17.06 compatible
H.265/H.264 dual-stream media server
Easy-to-use P2P Cloud service
Multi web browser, PC Client, mobile APP remote access
Optional customization Lens/Audio/POE, etc.
Lightning protection 4000V
Strong water-proof housing, IP66
IR distance 70-80 meters
HD 6-22mm Manual Lens
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
YC-W595ACHZ35A
-
Product name:
-
5mp LPR camera
-
Resolution:
-
2592(H)x1944 (V) 25fps
-
Lens:
-
6-22mm Motorized lens
-
IR LED:
-
4PCS White Light Array Leds
-
IR Distance:
-
80m
-
Image Sensor:
-
IMX335
-
POE:
-
Built in
-
Keyword:
-
Car plate capture
-
Working temperature:
-
-30℃-(+60)℃
-
Material:
-
Metal
Quick Details
-
Special Features:
-
Motion Detection, Waterproof / Weatherproof
-
Function:
-
NIGHT VISION, Wide Angle, White LED
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
YC-W595ACHZ35A
-
Product name:
-
5mp LPR camera
-
Resolution:
-
2592(H)x1944 (V) 25fps
-
Lens:
-
6-22mm Motorized lens
-
IR LED:
-
4PCS White Light Array Leds
-
IR Distance:
-
80m
-
Image Sensor:
-
IMX335
-
POE:
-
Built in
-
Keyword:
-
Car plate capture
-
Working temperature:
-
-30℃-(+60)℃
-
Material:
-
Metal
Products Description
Product Paramenters
|
Model
|
YC-W595ACHZ35A
|
|
Camera
|
|
|
Image Sensor
|
1/2.8" IMX335 CMOS
|
|
Effective Pixels
|
2592(H)×1944 (V)
|
|
Electronic Shutter
|
AUTO, 1/25s ~ 1/100000s
|
|
Min. Illumination
|
0.01Lux@F1.2(AGC ON), 0Lux IR on
|
|
Day/Night
|
Auto/Color/(B/W)/Timing
|
|
WDR
|
Digital WDR
|
|
White Balance
|
Auto
|
|
Other
|
AGC,2/3 DNR,Motion Detection, Privacy Mask, Mirror, Flip
|
|
Encode
|
|
|
Embedded Solution
|
Mstar MSC316DM
|
|
Video Standard
|
H.265/H.264
|
|
Video Resolution
|
MainStream:30fps@5MP(2592x1944),30fps@4MP/3MP,30fps@1080P/720P
|
|
|
Sub stream: D1/VGA(640x480)/360P/QVGA@25fps
|
|
Video Bitrates
|
512Kbps - 6Mbps, VBR/CBR
|
|
Audio Standard
|
G.711-u/G.711-a
|
|
IR Led
|
|
|
IR Led
|
4 White Array IR Led
|
|
IR Distance
|
70-80 meters
|
|
Lens
|
|
|
Focal length
|
6-22mm Manual lens
|
|
POE
|
YES
|
|
Network Services
|
|
|
Protocol
|
RTSP/FTP/DHCP/DDNS/NTP/SMTP/NFS
|
|
P2P
|
Yes
|
|
Web
|
IE , firefox 32bit ESR
|
|
Media
|
CMS, Android, IOS
|
|
0NVIF
|
17.06 compatible
|
|
General
|
|
|
Network Port
|
1-RJ45, 100Mbps, POE optional
|
|
Power Supply
|
12 VDC ± 10%
|
|
Power Consumption
|
< 5 W
|
|
Operating Temp.
|
-30℃-(+60)℃, 10%-90%RH
|
