Quick Details
-
Color:
-
full color
-
Panel Size:
-
250*250mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
MGF
-
Pixel Pitch:
-
7.81mm
-
Brightness:
-
3,000nits
-
pixel density:
-
16,384pixels/m2
-
Contrast Ratio:
-
3000:1
-
Color Depth:
-
22
-
Lifespan (hours):
-
100000
-
IP Rating:
-
IP65
-
HS Code:
-
8531200000
-
Resolution:
-
7.81
-
View Angle（H/V）:
-
160°/160°
-
Refresh rate:
-
3840Hz/s
-
Material:
-
Die-casting Aluminum
-
Certificate:
-
CE ROHS FCC CCC
-
Cabinet size:
-
500x500mm
-
Life span:
-
100000 Hs
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Usage:
-
Indoor Outdoor Rental LED Display
-
Product name:
-
Led Video Display Panel
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LED
-
Brand Name:
-
Madder
-
Color:
-
full color
-
Panel Size:
-
250*250mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
MGF
-
Pixel Pitch:
-
7.81mm
-
Brightness:
-
3,000nits
-
pixel density:
-
16,384pixels/m2
-
Contrast Ratio:
-
3000:1
-
Color Depth:
-
22
-
Lifespan (hours):
-
100000
-
IP Rating:
-
IP65
-
HS Code:
-
8531200000
-
Resolution:
-
7.81
-
View Angle（H/V）:
-
160°/160°
-
Refresh rate:
-
3840Hz/s
-
Material:
-
Die-casting Aluminum
-
Certificate:
-
CE ROHS FCC CCC
-
Cabinet size:
-
500x500mm
-
Life span:
-
100000 Hs
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Usage:
-
Indoor Outdoor Rental LED Display
-
Product name:
-
Led Video Display Panel
Products Description
Product Paramenters
|
Indoor and outdoor floor tile screens
|
|
|
|
|
|
|||||
|
Model Number
|
MGF2.6
|
MGF3.91
|
MGF3.91 Pro
|
MGF5.95
|
MGF7.81
|
|||||
|
Pixel Pitch
|
2.6mm
|
3.91mm
|
3.91mm
|
5.95mm
|
7.81mm
|
|||||
|
Physical Density
|
147,456pixels/m²
|
65,536pixels/m²
|
65,536pixels/m²
|
28,224pixels/m²
|
16,384pixels/m²
|
|||||
|
LED Arrangement
|
3 IN 1 SMD
|
3 IN1 SMD
|
3IN1 SMD
|
3 IN 1 SMD
|
3IN 1SMD
|
|||||
|
Module Resolution
|
96×96pixels
|
64x64pixels
|
64x64pixels
|
42x42pixels
|
32×32pixels
|
|||||
|
Module Dimensions
|
250×250mm(9.84×9.84in)
|
250×250mm(9.84×9.84in)
|
250×250mm(9.84×9.84in)
|
250×250mm(9.84×9.84in)
|
250×250mm(9.84×9.84in)
|
|||||
|
Cabinet Resolution
|
192×192pixels
|
128×128pixels
|
128×128pixels
|
84×84pixels
|
64×64pixels
|
|||||
|
Cabinet Dimensions
|
500×500×83.3mm
(19.7×19.7×3.28in)
|
500x500x83.3mm
(19.7×19.7×3.28in)
|
500×500×83.3mm
(19.7×19.7×3.28in)
|
500×500×84mm
(19.7×19.7×3.3in)
|
500×500×84mm
(19.7×19.7×3.3in)
|
|||||
|
Cabinet Weight
|
11.5kg(25.35Ib)
|
11.5kg(25.35Ib)
|
11.5kg(25.35Ib)
|
11.5kg(25.35Ib)
|
11.5kg(25.35|b)
|
|||||
|
Brightness
|
1,500nits
|
3,000nits
|
1,500nits
|
3,000nits
|
3,000nits
|
|||||
|
Max Power Consumption
|
180w/panel
|
180w/panel
|
180w/panel
|
180w/panel
|
180w/panel
|
|||||
|
Avg Power Consumption
|
60w/panel
|
60w/panel
|
60w/panel
|
60w/panel
|
60w/panel
|
|||||
|
Viewing Angle
|
160°/160°
|
120°/120°
|
160°/160°
|
120°/120°
|
120°/120°
|
|||||
|
Operating Power Source
|
100-240V AC 50-60Hz
|
100-240VAC 50-60Hz
|
100-240V AC 50-60Hz
|
100-240V AC 50-60Hz
|
100-240V AC 50-60Hz
|
|||||
|
Operating Temperature
|
-20°℃~+45℃
|
-20°℃~+45℃
|
-20℃~+45℃
|
-20℃~+45℃
|
-20°℃~+45℃
|
|||||
|
Refresh Rate
|
7,680Hz
|
3,840Hz
|
7,680Hz
|
3,840Hz
|
3,840Hz
|
|||||
|
IP Rating
|
IP65
|
IP65
|
IP65
|
IP65
|
IP65
|
|||||
|
Max Load-bearing
|
1,500kg/m²(3 times safety factor)
|
1,500kg/m²(3 times safety factor)
|
1,500kg/m²(3 times safety factor)
|
1,500kg/m²(3 times safety factor)
|
1,500kg/m²(3 times safety factor)
|
|||||
|
Signal Input Source
|
DVI,HDMI,DP,SDI
|
DVI,HDMI,DP,SDI
|
DVI,HDMI,DP,SDI
|
DVI,HDMI,DP,SDI
|
DVI,HDMI,DP,SDI
|
|||||
|
Verification
|
CE,FCC,ETL,ROHS,REACH
|
|
|
|
|
|||||
Certifications
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
