Quick Details
-
Brand Name:
-
SUNNYMED
-
Model Number:
-
SY-V920
-
Product name:
-
ophthalmic photodisruptor system
-
Laser Type:
-
Nd:YAG, Q-Switched
-
Wavelength:
-
1064 nm
-
Display:
-
7" TFT LCD Color Touch Screen
-
Corneal power:
-
33.00m-1~67.00m-1
-
Corneal astigmatism:
-
0.00m-1~15.00m-1
-
Corneal diameter:
-
2.00~ 12.00mm
-
Corneal Measurement:
-
Axis 0°~180° (Step 1°)
-
Printer:
-
57mm Printer Included
-
Power Supply:
-
AC220V; 50HZ
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SUNNYMED
-
Model Number:
-
SY-V920
-
Product name:
-
ophthalmic photodisruptor system
-
Laser Type:
-
Nd:YAG, Q-Switched
-
Wavelength:
-
1064 nm
-
Display:
-
7" TFT LCD Color Touch Screen
-
Corneal power:
-
33.00m-1~67.00m-1
-
Corneal astigmatism:
-
0.00m-1~15.00m-1
-
Corneal diameter:
-
2.00~ 12.00mm
-
Corneal Measurement:
-
Axis 0°~180° (Step 1°)
-
Printer:
-
57mm Printer Included
-
Power Supply:
-
AC220V; 50HZ
SUNNYMED Reliable Quality Affordable Price
lens capsulotomy surgery and vitreous surgery 1064nm Laser System for Ophthalmology
Why this mode?
YAG Laser System for Ophthalmology produces 1064nm wavelength laser pulse. The laser pulse
and dual-spot aiming beam can position precisely on the ocular tissue to be treated through slit-lamp microscope.
The YAG laser energy is concentrated and focused on a spot of about 30µm, producing light-induced explosion
effect in the action of such a high optical power density, to dissociate ocular tissue rapidly for a purpose of surgery.
The laser beam energy disperses rapidly in front of and behind the focal point so as to avoid injuries to tissues
outside the focal point resulting from laser beam. When the dispersed beam reaches fundus oculi, its power
density is below one ten thousandth of that at the focal point and the action time is only a few nanoseconds;
so under normal circumstances it is not easy to cause injury to fundus oculi thus ensured the safety of surgery.
The device has a built-in laser security protective system to guarantee continuous, stable and safe operation of the device.
The YAG laser and aiming laser are coaxial and confocal with the focal plane of the microscope
and meanwhile are confocal with the slit-lamp, which ensured the clarity of observation
and the accuracy of surgery. The device utilizes micro-processor control technique, with digital display and is easy to
operate; sophisticated ophthalmic micro-surgery can be implemented without cutting the eyeball,
which is simpler and easier than the conventional surgery, thus enhances the security.
and dual-spot aiming beam can position precisely on the ocular tissue to be treated through slit-lamp microscope.
The YAG laser energy is concentrated and focused on a spot of about 30µm, producing light-induced explosion
effect in the action of such a high optical power density, to dissociate ocular tissue rapidly for a purpose of surgery.
The laser beam energy disperses rapidly in front of and behind the focal point so as to avoid injuries to tissues
outside the focal point resulting from laser beam. When the dispersed beam reaches fundus oculi, its power
density is below one ten thousandth of that at the focal point and the action time is only a few nanoseconds;
so under normal circumstances it is not easy to cause injury to fundus oculi thus ensured the safety of surgery.
The device has a built-in laser security protective system to guarantee continuous, stable and safe operation of the device.
The YAG laser and aiming laser are coaxial and confocal with the focal plane of the microscope
and meanwhile are confocal with the slit-lamp, which ensured the clarity of observation
and the accuracy of surgery. The device utilizes micro-processor control technique, with digital display and is easy to
operate; sophisticated ophthalmic micro-surgery can be implemented without cutting the eyeball,
which is simpler and easier than the conventional surgery, thus enhances the security.
|
Laswer type
|
ND:YAG
|
|
Wavelength
|
1064nm
|
|
Mode
|
Q-Switch
|
|
Pulse Output:
|
1,2,3 pulse
|
|
Pulse width
|
4.5ns
|
|
Pulse Piepetition Rate
|
:2.5Hz
|
|
Output Energy
|
A) 1.Pulse maximum output:11Mj
B) 2 pulse maximum output:19Mj C) 3 pulse maximum output:28Mj D) Output Energy Rgulation:100%~6%,adjustable by 7 steps |
|
Cone Angle
|
18°
|
|
Spot size
|
30µm
|
|
Aiming Beam Wavelength
|
630~680nm
|
|
Aimeing output power
|
:<0.4Mw
|
