Quick Details
-
Throat Depth (mm):
-
0 mm
-
Brand Name:
-
WMTCNC
-
Power (kW):
-
7.5 kW
-
Weight (KG):
-
4000 KG
-
Place of Origin:
-
Anhui, China
-
Voltage:
-
220/380V
-
Year:
-
2020
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
metal forming:
-
hydraulic shearing
-
shear thickness:
-
6mm
-
shear width:
-
2500mm
-
backguage range:
-
20-600
-
Color:
-
Customizable
-
Material:
-
Steel Material
-
Machine type:
-
Cutting Machine Shearing Machine
-
Name:
-
Hydraulic Shearing Machine
-
Product name:
-
Metal Steel Cutting Machine
Quick Details
-
Max. Cutting Width (mm):
-
2500 mm
-
Max. Cutting Thickness (mm):
-
6 mm
-
Blade Length (mm):
-
500 mm
-
Throat Depth (mm):
-
0 mm
-
Brand Name:
-
WMTCNC
-
Power (kW):
-
7.5 kW
-
Weight (KG):
-
4000 KG
-
Place of Origin:
-
Anhui, China
-
Voltage:
-
220/380V
-
Year:
-
2020
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
metal forming:
-
hydraulic shearing
-
shear thickness:
-
6mm
-
shear width:
-
2500mm
-
backguage range:
-
20-600
-
Color:
-
Customizable
-
Material:
-
Steel Material
-
Machine type:
-
Cutting Machine Shearing Machine
-
Name:
-
Hydraulic Shearing Machine
-
Product name:
-
Metal Steel Cutting Machine
Product Description
Features of shearing machine:
1. Frame welded, vibration to eliminate stress, high in rigidity, sturdy an durable. Hydraulic drive, swing beam, return of knife
beam is smooth and prompt by accumulator or nitrogen cylinder, stead & reliable perfoman.
2. The position of low blade can be adjusted to ensure the epuilibrium of the gap after regrinding. the protable and prompt
adjusted of the blades gap, the value of gap is indicated by dial, positioning reliable.
3. Setting the backgauge by motor. The displessly devices used to the backgauge value and the shearing times are on the front of
the machine.
4. The stroke of knife or cbeam can be adjusted steplessly, conveniently an fast.
5. Preselection of single or continous strokes. Preselection of cutting number and cutting strokes
|
Specification
|
Shear Thickness
|
Shear Width
|
Shearing Angle
|
Number of Stroke
|
Backgauge Rang
|
Motor Power
|
|
|
mm
|
mm
|
(° )
|
min-1
|
mm
|
kw
|
|
QC12Y-4×2500
|
4
|
2500
|
1° 30
|
20
|
20~600
|
4
|
|
QC12Y-4×4000
|
4
|
4000
|
1° 30
|
18
|
20~600
|
5.5
|
|
QC12Y-6×3200
|
6
|
3200
|
1° 30
|
14
|
20~600
|
7.5
|
|
QC12Y-6×5000
|
6
|
5000
|
1° 30
|
10
|
20~800
|
11
|
|
QC12Y-8×2500
|
8
|
2500
|
1° 30
|
14
|
20~600
|
7.5
|
|
QC12Y-8×4000
|
8
|
4000
|
1° 30
|
8
|
20~600
|
7.5
|
|
QC12Y-8×6000
|
8
|
6000
|
1° 30
|
6
|
20~800
|
15
|
