Quick Details
-
Welding Current/Voltage Range:
-
260~600V
-
Place of Origin:
-
China
-
Brand Name:
-
Rosen or Customized
-
Pulse Frequency:
-
50~60Hz
-
Dimensions:
-
340mm*188mm*333mm
-
Use:
-
welding
-
Weight (KG):
-
8.06 KG
-
Type:
-
RS-MMA 300
-
Color:
-
Customized Color
-
Function:
-
Inverter IGBT Welding Machine
-
Technology:
-
Inverter IGBT Arc Welding Machine
-
Feature:
-
Small Size/Handheld
-
Efficiency:
-
100%
-
Hot start:
-
Easy Arc Ignition
-
Arc Current:
-
300A
-
Pilot Arc Current:
-
10A
-
Rated Duty Cycle:
-
100%
-
Voltage:
-
260~600V
-
Certification:
-
CE RoHS
-
Marketing Type:
-
Hot Product 2021
Quick Details
-
Rated Duty Cycle @40°C:
-
100%
-
Rated Input Voltage:
-
380V
-
Rated Output Voltage:
-
32 V
-
Welding Current/Voltage Range:
-
260~600V
-
Place of Origin:
-
China
-
Brand Name:
-
Rosen or Customized
-
Pulse Frequency:
-
50~60Hz
-
Dimensions:
-
340mm*188mm*333mm
-
Use:
-
welding
-
Weight (KG):
-
8.06 KG
-
Type:
-
RS-MMA 300
-
Color:
-
Customized Color
-
Function:
-
Inverter IGBT Welding Machine
-
Technology:
-
Inverter IGBT Arc Welding Machine
-
Feature:
-
Small Size/Handheld
-
Efficiency:
-
100%
-
Hot start:
-
Easy Arc Ignition
-
Arc Current:
-
300A
-
Pilot Arc Current:
-
10A
-
Rated Duty Cycle:
-
100%
-
Voltage:
-
260~600V
-
Certification:
-
CE RoHS
-
Marketing Type:
-
Hot Product 2021
Product Description
Specification
|
item
|
value
|
|
|
|
Mains Voltage(V)
|
380
|
|
|
|
Suitable Voltage Range(V)
|
260~600
|
|
|
|
Open circuit voltage(V)
|
15±5
|
|
|
|
Setting range for welding current(A)
|
10-300
|
|
|
|
Duty Cycle 40°C(A)
|
100% 300
|
|
|
|
Phases(50Hz-60Hz)/Max Arc Current(A)
|
300
|
|
|
|
Recommended generator power(KVA)
|
12
|
|
|
|
Color
|
Red/ Blue/Green
|
|
|
|
Weight (KG)
|
8.06
|
|
|
|
Dimensions(mm)
|
340*188*333
|
|
|
|
Weldable Electrode(mm)
|
1.6-5.0
|
|
|
|
Electrode
|
Acid,Basic,Stainless,Cast iron,Cooper,Aluminum etc
|
|
|
|
Protection classification
|
IP21
|
|
|
|
Insulation class
|
F
|
|
|
|
Standard
|
EN 60974-1:2012, EN 60974-10:2014
|
|
|
|
Safety marking
|
CE/RoHs
|
|
|
