Machine Name
|
LED UV liquid coating machine
|
|
Control System
|
PLC with Touch Screen. Automatic Running
|
|
Model Number
|
KANA-1700
|
|
Working Width
|
1650mm
|
|
Power
|
5kw
|
|
Voltage
|
220V 50/60Hz
|
|
Speed
|
1-12m/min
|
|
Coating Thickness
|
5～10um
|
|
Working Thickness
|
≤5mm
|
|
Curing System
|
LED - UV
|
|
LED Life Expectancy
|
15000 hours
|
|
Machine Size
|
2350*1500*1120mm
|
|
Packing Size
|
2450*1580*1300mm
|
|
NW/GW
|
680/980KGS
|
|
A
|
KANA coating performance test report (British SGS company)
|
|
1
|
Aging test report (coating has no quality change during 500 hours of water spraying and UV light cycle)
|
|
2
|
High temperature resistance test report (coating has no quality change under 68℃ within 48 hours)
|
|
3
|
Low temperature resistance test report (coating has no quality change under -20℃ within 48 hours)
|
|
B
|
KANA coating environmental protection test report (China National Coating Quality Supervision and Inspection Center, British SGS company)
|
|
1
|
Heavy metal and halogen test report provided by SGS
Test method: burn in a high-pressure oxygen bomb tank, the absorption of combustion products is analyzed by ion chromatography, and no volatile toxic gas will be generated
|
|
2
|
SGS inspection report provided by SGS
Test method: SVHC 211 high concern substance screening, SVHC test result ≤0.1% (W/W), pass the test standard
|
|
3
|
Volatile Organic Compound (VOC) Test Report
(By China National Coatings Quality Supervision and Inspection Center)
Test method: test condition (105±2)℃/h/about 1g, the test result is 246g/L |
|
No.
|
Service
|
Description
|
|
1
|
Lead Time
|
30 working days
|
|
2
|
MOQ
|
Machine 1 pcs, Matte or Glossy Varnish 200kg
|
|
3
|
Sample
|
Free Sample Available, 7 Days
|
|
4
|
Package
|
Plywood Box Carton Box
|
|
5
|
Price
|
EXW FCA FOB CIF DAT DDP
|
|
6
|
Payment
|
Credit / Debit Card, Paypal, Google Pay, ApplePay, WESTERN UNION, T/T ,L/C,
|
|
7
|
Shipping
|
By Sea Asia 10-15 days Europe 15-25 days America 15-30 days Africa 45 days
|
