Quick Details
-
Voltage:
-
380V
-
Rated Power:
-
50HZ
-
Year:
-
2020
-
Weight (KG):
-
3500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Control Accuracy:
-
+/-0.01mm
-
Max.pressure:
-
410Mpa
-
Cutting Accuracy:
-
+/-0.1mm
-
Way of Drive:
-
AC Servo
-
Intensifier:
-
Made in USA
-
PLC:
-
Omron
-
Main Motor:
-
Siemens
-
Continuous Working Pressure:
-
340 - 360Mpa
Quick Details
-
Place of Origin:
-
Liaoning, China
-
Marketing Type:
-
New Product 2022
-
Brand Name:
-
APW
-
Voltage:
-
380V
-
Rated Power:
-
50HZ
-
Year:
-
2020
-
Weight (KG):
-
3500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Control Accuracy:
-
+/-0.01mm
-
Max.pressure:
-
410Mpa
-
Cutting Accuracy:
-
+/-0.1mm
-
Way of Drive:
-
AC Servo
-
Intensifier:
-
Made in USA
-
PLC:
-
Omron
-
Main Motor:
-
Siemens
-
Continuous Working Pressure:
-
340 - 360Mpa
Benefits of Portable Waterjet Cutting
Explosion-proof cutting and derusting integrated machine, suitable for cutting chemical storage tanks, petrochemical pipelines, cylindrical metals, dismantling and repairing chemical plants, punching incisions, cleaning and derusting, etc. It is a safety equipment for cutting operations in flammable and explosive environments in chemical enterprises. Portable Waterjet can cut any material with a thickness of 0-100mm (except diamond and special carbide).
Portable Waterjet adopts the form of double feeding of front and rear mixing, the front mixing is used for cutting, and the rear mixing is used for rust removal. It can not only cut various plates, pipes and profiles, but also remove rust, oxide scale, paint and residual oil on metal surfaces. Compared with other cutting methods, the advantages are: no high temperature, no open flame, no static electricity, no harmful gas
|
Item |
Parameter value |
|
|
Nominal Pressure |
N50 Mpa | |
|
Cutting Conditions |
Orifice Diameter | 1.2mm |
| Speed (5mm stainless steel ) | N180 mm/min | |
| Feeding Form |
Pre-mixing |
|
|
Rust removal (cleaning) condition |
Orifice Diameter | 1*3 mm |
| Speed | NO.4 m 2 /min | |
| Feeding Form |
After-fixing |
|
| Noise sound Pressure Level | W90 dB (A) | |
|
Demension ( Lx Wx H ) |
HP Power Protection system |
1620X500X790 mm |
| HP mortar mixing system |
420X420X860 mm |
|
|
Machine weight |
High voltage Power protection system |
W360 kg |
|
HP mortar cum vertical |
W90 kg | |
|
HP water pump |
Motor Model |
YB3-180L-4 |
|
Power |
22 kw | |
|
Voltage |
380/660 V | |
| Current | 42. 4/24. 5 A | |
|
Pump Flow |
N22 L/mi n | |
|
Abrasive type |
Silicon carbide |
|
