Quick Details
-
Main Materials:
-
Steel
-
Color:
-
Customized
-
Floor:
-
MGO Board/cement-fibre board
-
Wall Panel:
-
EPS/Rock wool sandwich panels
-
Window:
-
Aluminum Window/Plastic steel window
-
Door:
-
Galvanized baking paint security door
Quick Details
-
Place of Origin:
-
Jiangsu, China, Suzhou, China (Mainland)
-
Brand Name:
-
zhongnan, Zhongnan
-
Model Number:
-
ZN-001
-
Main Materials:
-
Steel
-
Color:
-
Customized
-
Floor:
-
MGO Board/cement-fibre board
-
Wall Panel:
-
EPS/Rock wool sandwich panels
-
Window:
-
Aluminum Window/Plastic steel window
-
Door:
-
Galvanized baking paint security door
ADVANTAGES
1.
We are the
professional
manufacturer,
The visible parts of the house can be customized, including doors, windows, interior and exterior walls, roof, etc. Color,material, version, thickness, etc. can be customized according to customer needs.
2.
The sandwich wall panel uses fire-retardant materials. The thickness of wall panel is 50mm-100mm, It has good insulation, can be used in extremely cold areas
3.
Excellent waterproof performance,no leakage of rain.
Environmental protection , can be reused many times and no construction waste.
4.
Professional installation personnel can go to the designated area to install or guide
the installation.
5.
We can design the house toany size you need and effi-ciently complete the servicechain from processing tohandling to delivery
6.
Structural beams and other plates are made of thickened raw materials and molded by stamping process, with a service life of 35 years. More than 15 years than ordinary container house service life.
7.
The surface adopts electrostatic spraying process.
8.
Modular building , Can be used in office building , workers dormitories , hotels , hospitals , warehousing,classrooms etc.
Product Description
|
Container House Parameters
|
|
|
||
|
Size
|
20FT/40FT Customized
|
|
||
|
Life span
|
More than 35 years
|
|
||
|
Steel Frame
|
Main Beam For Floor And Bottom
|
Galvanized formed beam
|
||
|
|
|
Thickness:3.0mm,2.5mm,2.3mm
|
||
|
|
Top Frame
|
C shape steel:C80*1.3mm,galvanized
|
||
|
|
|
Square tube: 20*20*1.0mm,galvanized
|
||
|
|
|
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³
|
||
|
|
Bottom Frame
|
Square tube: 50*100*1.2mm,galvanized
|
||
|
|
|
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³
|
||
|
|
Column
|
Galvanized steel Column
|
||
|
|
Corner fitting
|
Galvanized steel
|
||
|
Wall system
|
75mm Sandwich Panel
|
75mm rock wool board,density≥80kg/m3
|
||
|
Floor
|
Fiber Cement Board
|
Thickness :18mm
|
||
|
|
Vinyl flooring
|
Thickness:1.6mm/2.0mm
|
||
|
Roof
|
Ceiling
|
V-831 type,0.4mm Integrated Color Steel Sheet
|
||
|
Window
|
Sliding Window
|
925mm*1100mm
|
||
|
Door
|
Steel Security Door
|
840mm*2035mm
|
||
|
Electrical Device
|
100V- 250V, 2P63A, Using IP44 standard power distribution box. main power cable is 6m², AC cable is 4m², socket cable is 2.5m²,lighting & switch cable is 1.5m².
Four sockets, 1pc AC socket of three holes 16A, 3pcs socket of five holes 10A. 1pc single connection switch, 2pcs LED light,2*15W.ADAPTS power supply according to different countries and regions |
|
||
|
Accessories
|
Screw ,Blot, Silicon sealant,etc
|
|
||
The basic layout of the 20ft villa house includes three bedrooms, a kitchen, a living room, and a bathroom.We have a variety of interior layouts to choose from.The kitchen will be equipped with cabinets and a sink, while the bathroom will feature a separate shower area, a bathroom cabinet, and a toilet.All doors,windows, flooring,Terrace,internal wiring,switches,sockets,and drainage pipes will be installed within the house for convenient use.Moreover, we will provide sockets and switches that comply with the standards of your country.
House Entirety Size: 9000mm*9000mm*3800mm (29.52ft*29.52ft*12.47ft)
House Inside Size: 9000mm*6000mm*3800mm (29.52ft*19.69ft*12.47ft)
House External Size: 9000mm*3000mm*3800mm (29.52ft*9.84ft*12.47ft)
One Livingroom
Three Bedroom
One Restrooms
One Livingroom
One Bedroom
One kitchen
One Livingroom
Two Bedroom
One Kitchen
* We have a wide range of design options for you to choose from
Wooden Tiny Container Villa
Glass Wall Tiny Container Villa
The Tiny Container Villa All configurations are customizable.
