Quick Details
-
Model Number:
-
NBN40-L2-E2-V1
-
Type:
-
PNP
-
Power:
-
10ma
-
Sensing Range:
-
40 mm
-
Product name:
-
Touch Switch Capacitive Sensor
-
Certification:
-
CE
Quick Details
-
Voltage:
-
10 ... 30 V DC
-
Place of Origin:
-
GUA
-
Brand Name:
-
P+F
-
Model Number:
-
NBN40-L2-E2-V1
-
Type:
-
PNP
-
Power:
-
10ma
-
Sensing Range:
-
40 mm
-
Product name:
-
Touch Switch Capacitive Sensor
-
Certification:
-
CE
Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
GUA
|
|
Brand Name
|
P+F
|
|
Model Number
|
NBN40-L2-E2-V1
|
|
Warranty
|
Other
|
|
Type
|
PNP
|
|
Certification
|
CE
|
|
Power
|
10ma
|
|
Voltage
|
10 ... 30 V DC
|
|
Customized
|
NO
|
|
Sensing Range
|
40 mm
|
|
Whether the smart
|
NO
|
|
Product name
|
Touch Switch Capacitive Sensor
|
Sensor head bi-directional and rotatable
4 LED indicator lights, 360° visibility
40 mm, not flush
3-wire direct current
Quick mounting bracket
Technical parameters excerpt NBN40-L2-E2-V1
General specification
Switch function normally on (NO)
Output type PNP
Rated working distance 40 mm
The installation is not flush
Output polarity DC
Make sure the operating distance is 0... 32,4 mm
Actual working distance 36... 44 mm
Attenuation coefficient rAl 0,33
Attenuation coefficient rCu 0,31
Attenuation coefficient r304 0,74
Attenuation coefficient rBrass 0,38
Output type 3 lines
rating
Operating voltage 10... 30 V DC
Switching frequency 0... 180 Hz
Hysteresis type 5 %
Reverse polarity protection Reverse polarity protection
Short circuit protection pulse type
Voltage drop ≤ 2 V
Operating current 0... 200 mA
Off-state current 0... 0,5 mA
No load current ≤ 20 mA
Time delay before availability is 80 ms
Operating voltage indicator green LED
Switch status indicator yellow LED
Functional safety-related parameters
MTTFd 1510 a
Task time (TM) 20 a
Diagnostic coverage (DC) 0 %
Comply with standards and instructions
Meet the standard
Standard EN 60947-5-2:2007
EN 60947-5-2/A1:2012
IEC 60947-5-2:2007
IEC 60947-5-2 AMD 1:2012
Certification and certificate
Protection Class II
Rated insulation voltage 253 V
Rated impulse withstand voltage 4000 V
UL Certification cULus Certification, general purpose
When the rated voltage of CCC certification is less than or equal to 36 V, the product does not need CCC certification/marking
Environmental conditions
Ambient temperature -25... 85 °C (-13... 185 °F)
Storage temperature -40... 85 °C (-40... 185 °F)
Mechanical specification
Connection Type Connector Plug M12 x 1, 4 pins
Shell material PA
Induction surface PA
Protection level IP68 / IP69K
cable
Cable diameter 3,3 mm ± 0,15 mm
Mass 130g
