Quick Details
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
ginpertec
-
Frequency:
-
1.7 mhz
1. Ultrasound nebulizer with 1.7M /2.4 M frequency (nebulizer frequency can also be changed according to customer requirements
2. Potentiometer can be used to adjust the size of atomization
3. Use the reed tube to detect water shortage. It is sensitive to react. At the first moment, it ensures that the atomizer
prevents dry burning, protects the life of the whole machine. Red light indication when water shortage occurs and green light
indication when normal.
3. Inside 24V Fan Drive
2. Potentiometer can be used to adjust the size of atomization
3. Use the reed tube to detect water shortage. It is sensitive to react. At the first moment, it ensures that the atomizer
prevents dry burning, protects the life of the whole machine. Red light indication when water shortage occurs and green light
indication when normal.
3. Inside 24V Fan Drive
|
Model
|
GPWH-4F1.7-2016
|
GPWH-4F2.4-2016
|
GPWH-4F3-2016
|
GPWH-4F1.7-2520
|
GPWH-4F2.4-2520
|
GPWH-4F3-2520
|
|
Overall Diameter
|
20mm
|
20mm
|
20mm
|
25mm
|
25mm
|
25mm
|
|
Piezo Dimater
|
16mm
|
16mm
|
16mm
|
20mm
|
20mm
|
20mm
|
|
Resonant frequency(Fs)
|
1.7mhz
|
2.4mhz
|
3mhz
|
1.7mhz
|
2.4mhz
|
3mhz
|
|
Resonant impedance (Zr)
|
＜2.5mm
|
＜2.5
|
＜2.5
|
＜2.5
|
＜2.5
|
＜2.5
|
|
Voltage (V)
|
≤ 36
|
≤ 36
|
≤ 36
|
≤ 36
|
≤ 36
|
≤ 36
|
|
Driver Power (w)
|
24
|
12
|
5
|
24
|
12
|
5
|
|
Dry
|
＜30
|
＜30
|
＜30
|
＜30
|
＜30
|
＜30
|
|
Working Temperature
|
5-40’C
|
5-40’C
|
5-40’C
|
5-40’C
|
5-40’C
|
5-40’C
|
|
Electrode protector
|
Glass glaze
|
Glass glaze
|
Glass glaze
|
Glass glaze
|
Glass glaze
|
Glass glaze
|
|
Electrode Material
|
Ag
|
Ag
|
Ag
|
Ag
|
Ag
|
Ag
|
|
Water Quality
|
Drinking water
|
Drinking water
|
Drinking water
|
Drinking water
|
Drinking water
|
Drinking water
|
|
Atomizing Quantity(mL)
|
350/min
|
250/min
|
200/min
|
350 /min
|
250/min
|
200/min
|
|
Life (h)
|
5000
|
5000
|
5000
|
5000
|
5000
|
5000
|
|
Capacitance (pF)
|
1500±20%
|
1500±20%
|
1500±20%
|
1500±20%
|
1500±20%
|
1500±20%
|
