frp plastic bar grating/fiberglass frp plastic grid grating platform

frp plastic bar grating/fiberglass frp plastic grid grating platform

FOB Reference Price: Get Latest Price

≥1 Square meters

US $9

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: DRS

Model Number:: CIA-C-2

Surface Treatment:: Concave

Dimensions:: Customizable

Product name:: plastic grid platform

Material:: E-glass, ISO and ATH

Color:: Yellow, red, white, grey, green

Certificate:: ISO9001:2008, CE

Thickness:: 38mm, 40mm, 50mm, 60mm, 70mm and so on

bar thikness:: 6.0/5.0, 7.0/5.0, 6.5/5.0 and so on

Weight:: 19.5-100kg

Function:: anti-fire, anti corrosion, stainless

Quick Details

Application:: platform, industrial

Technique:: Molded

Place of Origin:: Jiangsu, China

Brand Name:: DRS

Model Number:: CIA-C-2

Surface Treatment:: Concave

Dimensions:: Customizable

Product name:: plastic grid platform

Material:: E-glass, ISO and ATH

Color:: Yellow, red, white, grey, green

Certificate:: ISO9001:2008, CE

Thickness:: 38mm, 40mm, 50mm, 60mm, 70mm and so on

bar thikness:: 6.0/5.0, 7.0/5.0, 6.5/5.0 and so on

Weight:: 19.5-100kg

Function:: anti-fire, anti corrosion, stainless

Product Description

frp plastic bar grating/fiberglass frp plastic grid grating platform

concave, gritted surface

anti skid

mini/micro mesh surface

Could prevent objects from falling through.

Solid cover

Anti skid and prevent liquid leaking and gas volatilizing.

smooth surface

It can be used for decoration such as doors, partitions, ceilings, etc.

Parameters
Type	frp plastic bar grating/fiberglass frp plastic grid grating platform
Material	ECR Glass Fiber + Resin (ORTHO,ISO,VE,PHENOLIC)+Filling (ATH)
Mesh Size	383838mm，404040mm, etc. can be customized (pls check detail as below form)
Color	According to RAL Book.Yellow, Orange, Blue, Green, Grey, etc. can be cutomized
Surface	Gritted, Smooth, Concave, Solid Top Covered

Anti-Fire/Corrosion/UV

Light Weight/High Strength

Safety/Easy Installation

Size-Molded Grating

Mesh Size (mm)	Thickness (mm)	Bar Thickness(mm)	Standard Panel Size(mm)
38x38	13	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	14	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	15	6.0/5.0	1220x3660,1220x4000,1220x2440
	20	6.0/5.0	1220x3660,1220x4000,1524x4010,997x3012
	25	6.5/5.0	1220x3660,1226x4010,1524x4000,1530x4010,1997x3012
	30	6.5/5.0	1220x3660,1220x4010,1524x4010,921x3055
	38	7.0/5.0	1220x3660,1220x4010,2100x4240,998x4010,1220x2440
	50	9.5/7.5	1220x4010,1220x3666,1230x4010,1220x2440,921x3055
	60	10.5/8.5	1230x4010
	70	11.0/9.0	1230x4010
40x40	25	7.0/5.0	1007x3007,1007x4007,1247x4047,1527x4047
	30	7.0/5.0	1527x4047,1007x3007,1247x4047
	38	7.0/5.0	1527x4047,1247x4047,1007x3007,1007x4047
	40	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
50x50	15	6.0/5.0	1228x4020,1220x3660,1220x2440
	40	6.8/5.0	1787x4530,1225x4530
	25	7.0/6.0	1220x3660,1226x4020,1220x2440,915x3050
	50	8.0/6.0	1524x4000,1220x3660,1220x2440,1220x4000
83x83	38	7.0/5.0	1007x4007,1007x3007,1007x4255
83x83	40	7.0/5.0	1007x4007,1007x3007,1007x4255
13x13/40x40 micro mesh	25	6.5/4.5/5.0	1247x4047,1007x3007,1007x4047,1530x4047
	30	6.5/4.5/5.0	1527x4047,1247x4047,1007x3007,1007x4047
	38	6.5/4.5/5.0	1527x4047,1247x4047,1007x3007,1007x4047
19x19/38x38 mini mesh	25	6.5/5.0	1220x3660,1220x2440,921x3055,1226x4007,1268x4007
	30	6.5/5.0	1220x3660,1220x2440,921x3055,1220x4000,1530x4047
	38	6.5/5.0	1220x3660,1220x2440,921x3055,1220x4000,1226x4010
20x20/40x40 mini mesh	14	6.5/5.0	1007x3007,1247x4047
	22	6.5/5.0	1527x4047,1007x3007,1247x4047
	25	6.5/5.0	1527x4047,1247x4047
	30	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
	38	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
	40	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
25x25/50x50 mini mesh	50	8.0/6.0	1532x4020
26x26/52x52 mini mesh	30	7.0/6.0	1530x4000,1532x4050
26x26/52x52 mini mesh	38	6.0/5.0	1517x4015
25x50	38	11.0/9.0	1220x1835
25x50	50	12.0/9.0	1220x1835
25x100	25	7.0/5.0	1220x3660,915x3050
38x100	38	8.0/6.0	1226x3665,1530x4047,921x3050
25x152	38	8.0/6.5	1220x3660,1220x2440,1220x4124,921x3050
38x152	38	8.0/6.0	1220x3660,1220x2440,915x3050
