Quick Details
-
Keyword:
-
spiral duct production machine
-
Color:
-
Customizable
-
Function:
-
Air Conditioning auto duct line
-
Name:
-
spiral tube forming machine,round duct forming machine
-
Usage:
-
making HVAC Pipe
-
Material:
-
Carbon Steel
Quick Details
-
Pipe Material:
-
Carbon steel
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
Elbow Making Machine
-
Keyword:
-
spiral duct production machine
-
Color:
-
Customizable
-
Function:
-
Air Conditioning auto duct line
-
Name:
-
spiral tube forming machine,round duct forming machine
-
Usage:
-
making HVAC Pipe
-
Material:
-
Carbon Steel
Auto square duct making line spiral tube forming machine,Galvanized steel spiral round duct forming machine for air duct making and tube former,High quality spiral tube former machine,Hvac spiral duct production machine
Video in Youtube:
https://youtu.be/RcUOO2txiuE
Product Photos:
Features :
• Special mould for various tube diameters, very easy to change and adjust, no need crane or too much manpower
• Large diameter range
• High speed synchro flying cutting system
• PLC control, convenient operation
• Light and small, site work
• Perfect swage, without leakage
Main Technical Data:
|
Diameter range |
Φ80-Φ1500mm |
|
Tube Length |
120-8000mm |
|
Thickness of Strip |
0.4-1.2mm 0.8mm stainless steel |
|
Width of Strip |
137-140mm |
|
Strip Speed |
1-38/min |
|
Dimension (L x W x H): |
34 50* 20 50*2 72 0mm |
|
Lock seam |
Outside tube, on the inside on request |
|
Weight |
18 00kg |
|
Control System |
PLC automatic control |
|
Compressed air power |
0.5-0.7kmp |
|
Electrical |
380V/3PH/50HZ(According to customer’s request) |
|
Main Motor Power |
5.5kw |
|
The power of cutting motor |
4kw |
|
Suitable Material |
Aluminum, Stainless steel, Galvanized steel |
Fixed mold type Spiro tube forming machine and gore lock machines:
