Quick Details
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
CRF250-1
-
Engine:
-
CGB250/CBB250CC Single cylinder,Air/Oil-Cooled,Four Stroke
-
Color:
-
Red/Black/Blue/Green/Orange Etc.
-
Wheel Type:
-
Spoke wheel
-
Brake:
-
Front Disc/Drum brake, Rear Disc/Drum brake
-
Fuel Consumption:
-
≤354g/Kw.h
-
Shock Absorber:
-
Invert shock absorber and Mono rear suspension
-
Tyre:
-
Off Road Deep Teeth Tires
Quick Details
-
Displacement:
-
200-400CC
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Other
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
CRF250-1
-
Engine:
-
CGB250/CBB250CC Single cylinder,Air/Oil-Cooled,Four Stroke
-
Color:
-
Red/Black/Blue/Green/Orange Etc.
-
Wheel Type:
-
Spoke wheel
-
Brake:
-
Front Disc/Drum brake, Rear Disc/Drum brake
-
Fuel Consumption:
-
≤354g/Kw.h
-
Shock Absorber:
-
Invert shock absorber and Mono rear suspension
-
Tyre:
-
Off Road Deep Teeth Tires
Product Introduction
Specification
|
ENGINE
|
|
|
|
Engine Type:
|
Single cylinder,air-cooled,four stroke,
|
|
|
Displacement (ml):
|
223
|
|
|
Bore X Stroke(mm):
|
65.5×66.2
|
|
|
Compression Ratio:
|
9.25:1
|
|
|
Max. Power (kw/r/min)
|
12/7500
|
|
|
Max. Torque (N.m/r/min):
|
18/5500
|
|
|
Max. Speed (Km/h):
|
≥85
|
|
|
Lubrication:
|
Pressure ,splash
|
|
|
Clutch Type:
|
Multiplate wet clutch, Manual
|
|
|
Ignition:
|
CDI
|
|
|
Starting System:
|
Electric/Kick Start
|
|
|
Transmission System:
|
Chain drive
|
|
|
The left and right steering angle
|
left 39º right 40º
|
|
|
CHASSIS
|
|
|
|
Front Brake:
|
disc/drum brake
|
|
|
Rear Brake:
|
drum brake
|
|
|
Front Tire:
|
3.50-17
|
|
|
Rear Tire:
|
4.60-17
|
|
|
Battery:
|
12V/7AH
|
|
|
DIMENSIONS
|
|
|
|
L X W X H (mm):
|
2000*800*850
|
|
|
Seat Height (mm):
|
850
|
|
|
Wheelbase (mm):
|
1340mm
|
|
|
Min. Ground Clearance(mm):
|
200
|
|
|
Max. Permissionable Weight (kg):
|
165
|
|
|
Rider Capacity:
|
2 Person
|
|
|
Dry. Weigth (kg):
|
145
|
|
|
Engine Oil (L):
|
1L SAE15W/40
|
|
|
Fuel Tank Capacity (L):
|
14
|
|
|
Roll angle (°)
|
10°
|
|
