Quick Details
-
Clutch:
-
double clutch
-
Tire:
-
6.0-16/9.5-24
-
Implements:
-
harrow plough tiller
-
Options:
-
cabin
-
Color:
-
Customized/customized
Quick Details
-
Place of Origin:
-
Shandong, China
-
Product name:
-
mini traktor 4x4
-
Engine:
-
laidong diesel engine
-
Clutch:
-
double clutch
-
Tire:
-
6.0-16/9.5-24
-
Implements:
-
harrow plough tiller
-
Options:
-
cabin
-
Color:
-
Customized/customized
mini traktor 4x4 specification
|
mini traktor 4x4 SPECIFICATION |
|||
|
Model |
304 |
404 |
504 |
|
Drive type |
4*4 |
4*4 |
4*4 |
|
Engine |
|
||
|
Engine brand |
LD |
LD |
LD |
|
Model |
KM390BT |
4L23BT |
4L100 |
|
Type |
3 cylinder,water-cooling, In-line, direct injection |
4 cylinder,water-cooling, In-line, direct injection |
4 cylinder,water-cooling, In-line, direct injection |
|
Rated speed (r/min) |
2300 |
2300 |
2300 |
|
Engine power ( hp ) |
30hp/22.1kw |
40hp/29.4kw |
50hp/36.8kw |
|
Transmission |
|||
|
Clutch |
Dry, single or double clutch |
Dry, single or double clutch |
Dry, single or double clutch |
|
PTO size |
6 teeth φ35 |
6 teeth φ35 |
6 teeth φ35 |
|
PTO Speed(rpm) |
540/720 |
540/720 |
540/720 |
|
Gear shift |
( 4+1 ) *2 |
( 4+1 ) *2 |
( 4+1 ) *2 |
|
Hydraulic system |
|||
|
Hydraulic output valve |
2-Way opitonal |
2-Way opitonal |
2-Way opitonal |
|
Three point linkage |
|||
|
Category of 3-point link |
Category I |
Category I |
Category I |
|
Lifting capacity(at point
|
> 6.4 |
>7 .4 |
>8 .4 |
|
Technical parameter |
|||
|
Dimension ( L*W*H ) mm |
3000*1500*1900 |
3000*1500*1900 |
3150*1500*1900 |
|
Min.Net weight |
1350kg |
1400kg |
1500kg |
|
Wheel base(mm) |
1900 |
1900 |
1900 |
|
Front wheel tread(mm) |
1200 |
1200 |
1200 |
|
Rear wheel tread(mm) |
1200 |
1200 |
1200 |
|
The Min. clearance(mm) |
360 |
360 |
360 |
|
Front tyre |
6.0-16/6.5-16 |
6.0-16/6.5-16 |
6.0-16/6.5-16 |
|
Rear tyre |
9.5-24/11.2-24 |
9.5-24/11.2-24 |
9.5-24/11.2-24 |
|
Steering type |
Hydraulic Steering |
Hydraulic Steering |
Hydraulic Steering |
Packing Details : Overall packaging or iron frame
Delivery Details : 15 -20 days based on your quantity
Shipping :
At first,we will shipping according to your requirement.
Than,we will choose better shipping way for you if you need,Currently we have Qingdao Port
