Quick Details
-
Brand Name:
-
Aiphonso
-
Supply Voltage:
-
AC220V
-
Standard or Nonstandard:
-
Standard
-
Housing Material:
-
Brass and plastic
-
Quality control system:
-
ISO9001:2008
-
Discharge time:
-
0.5-10 Seconds to adjust
-
Interval time:
-
0.5-45 Minutes to adjust
-
Certification:
-
ISO9001
Quick Details
-
Port Size:
-
1/8"-1/2"
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
PT CS-720
-
Brand Name:
-
Aiphonso
-
Supply Voltage:
-
AC220V
-
Standard or Nonstandard:
-
Standard
-
Housing Material:
-
Brass and plastic
-
Quality control system:
-
ISO9001:2008
-
Discharge time:
-
0.5-10 Seconds to adjust
-
Interval time:
-
0.5-45 Minutes to adjust
-
Certification:
-
ISO9001
Ordering code
|
CS
|
15
|
SS
|
AC110V
|
|
2/2 Way
|
Port Size
|
Body Material
|
Standard Voltage
|
|
|
15:1/2"
|
SS:Stainless steel
|
DC12V
|
|
|
20:3/4"
|
B:Brass
|
DC24V
|
|
|
25:1"
|
|
AC24V
|
|
|
35:1-1/4"
|
|
AC110V 50HZ/60HZ
|
|
|
40:1-1/2"
|
|
AC220V 50HZ/60HZ
|
|
|
50:2"
|
|
AC380V 50HZ/60HZ
|
Specification
|
Model
|
CS-15
|
CS-20
|
CS-25
|
CS-35
|
CS-40
|
CS-50
|
|||||
|
Working Medium
|
Air,Water,Steam
|
|
|
|
|
|
|||||
|
Action Type
|
Pilot opterated(Normally close)
|
|
|
|
|
|
|||||
|
Orifice Size
|
17
|
|
22
|
30
|
|
50
|
|||||
|
CV Value
|
4.8
|
|
12
|
20
|
|
48
|
|||||
|
Port Size
|
1/2"
|
3/4"
|
1"
|
1-1/4"
|
1-1/2"
|
2"
|
|||||
|
Pressure
|
0.1~1.5MPa
|
|
|
|
|
|
|||||
|
Medium Temperature
|
-5~180℃
|
|
|
|
|
|
|||||
|
Material of Body
|
Brass or Stainless Steel
|
|
|
|
|
|
|||||
|
Material of Seal
|
PTFE
|
|
|
|
|
|
|||||
