Quick Details
-
Production Capacity:
-
High
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
STONE MATE
-
Voltage:
-
380V 220V Optional
-
Dimension(L*W*H):
-
5800*4800*3200mm
-
Weight:
-
6800 kg, 6800kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Infrared Bridge stone automatic cnc cutting machine
-
Color:
-
Blue
-
use:
-
cutting stone
-
certification:
-
CE
-
Max Cutting thickness:
-
2500mm
-
After Warranty Service:
-
Video technical support
-
Product name:
-
Marble Cutter Machine
Quick Details
-
Type:
-
Stone Cutting Machine
-
Power:
-
18.5kw
-
Cutting thickness (max):
-
Other
-
Production Capacity:
-
High
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
STONE MATE
-
Voltage:
-
380V 220V Optional
-
Dimension(L*W*H):
-
5800*4800*3200mm
-
Weight:
-
6800 kg, 6800kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Infrared Bridge stone automatic cnc cutting machine
-
Color:
-
Blue
-
use:
-
cutting stone
-
certification:
-
CE
-
Max Cutting thickness:
-
2500mm
-
After Warranty Service:
-
Video technical support
-
Product name:
-
Marble Cutter Machine
Detail:
Features:
Durable: Good quality steel is used as the mechanical parts and reliable imported electric,Parts are used to guarantee high reliable & durable.
Precise: a. Crossbeam movement(Y-axis)along linear guide way with high precision.
b. Z-axis movement by lead screw.
c. Magnetic ruler is adopted for slicing measure.
d. Laser device for accurate alignment.
Userfriendly: a. Touch screen control panel and 3D movement is controlled by microcomputer to realize automatic operation.
b. Both manual and automatic operation available .
c. Workable can rotate 90o or 360O( optional).
Multi-functional: With optional sensor ,profiling function can be added.
|
Technical Parameter |
SQQ-800B |
|
Blade diameter |
Φ 600-800mm(400-800mm add a VFD) |
|
Blade up/down stroke |
600mm |
|
Main motor |
18.5kw |
|
Feeding motor |
3kw |
|
Slicing motor |
1.1kw |
|
Rotation angle of blade axis |
0-5 |
|
Max.cutting size |
3200*2000*200mm |
|
Workbench rotating degree |
0-90:45-90-135-360;1-360 |
|
Workbench tilting degree |
0-85 |
|
Dimension (L*W*H) |
5800*4800*3200mm |
|
Weight |
6800kg |
a. Each product is packed in an inner cardboard case, and then several of inner cases are put into an export standard carton, then reinforced with straps.
b . Normally we can make shipment within 7-15 days after receiving your payment or L/C .
