Quick Details
-
Mold Height(mm):
-
120 - 320 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
181 cm³
-
Injection Rate (g/s):
-
95 g/s
-
Injection Weight (g):
-
165 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
38 mm
-
Screw L/D Ratio:
-
22
-
Weight (KG):
-
3500 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
340 mm
-
Model Number:
-
HJF118
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
6.5 kW
-
After-sales Service Provided:
-
Overseas third-party support available
-
Plastic injection moulding machine:
-
injection molding machine
-
Origin:
-
China
-
screw diameter:
-
38
-
clamp tonnage:
-
1180
-
toggle stroke:
-
340
-
ejector stroke:
-
100
-
heater power:
-
6.5
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
370mm
-
Distance between Tie Bars(Height)(mm):
-
370mm
-
Plasticizing Capacity(g/s):
-
95
-
Mold Height(mm):
-
120 - 320 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
181 cm³
-
Injection Rate (g/s):
-
95 g/s
-
Injection Weight (g):
-
165 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
38 mm
-
Screw L/D Ratio:
-
22
-
Weight (KG):
-
3500 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
340 mm
-
Model Number:
-
HJF118
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
6.5 kW
-
After-sales Service Provided:
-
Overseas third-party support available
-
Plastic injection moulding machine:
-
injection molding machine
-
Origin:
-
China
-
screw diameter:
-
38
-
clamp tonnage:
-
1180
-
toggle stroke:
-
340
-
ejector stroke:
-
100
-
heater power:
-
6.5
PU shoe sole injection molding machine
We supply all kinds of injection molding machines from
25T to 3000T,
including color chips making machines,
energy saving injection molding machines, gears making machines, dual clear color injection molding machine bakelite injection molding machines, PET preform injection molding machines, Fixed pump and variable pump injection molding machines, PVC fitting injection molding machines and etc
.
1. EPS USED yizumi injection molding machine
Real photo for Injection Molding Machine,It is in stock.25 days,we can arrange shipment after order confirmed.
Advanced hydraulic system design, through proportional control of pressure, flow achieves rapid multi-level pressure, speed switching, the system configuration is reasonable, stable and
reliable.
| Parameter | Unit | HJF118-F5 | ||
| Screw diameter | mm | A | B | C |
| 35 | 38 | 40 | ||
| Screw I/D ratio | L/D | 23.9 | 22 | 20.9 |
| shot volumn (theoretical) | Cm 3 | 154 | 181 | 201 |
| injection weight(PS) | g | 141 | 165 | 183 |
| injection rate | g/s | 80 | 95 | 105 |
| injection pressure | Mpa | 219 | 186 | 167 |
| screw speed | r/min | 0~220 | ||
| clamp force | KN | 1180 | ||
| opening stroke | mm | 340 | ||
| space between tie bars (W*H) | mm | 370*370 | ||
| max mould height | mm | 400 | ||
| min mould height | mm | 150 | ||
| ejector stroke | mm | 100 | ||
| ejector force | KN | 33 | ||
| ejector number | PC | 5 | ||
| max pump pressure | Mpa | 16 | ||
| pump motor power | KW | 11 | ||
| heating power | KW | 6.5 | ||
| machine dimension | M | 4.2*1.25*1.8 | ||
| machine weight | T | 3.5 | ||
| oil tank capacity | L |
210
|
||
2.The products made by injection molding machine
Most plastic products is made by injection molding machine,Say: pipe fitting, pet preform, disposable spoon knife fork,bow,cup,container,pallet, food container. etc.
3.Auxiliary Equipment for Injection Molding Machine
Auto loader,Chiller,Crusher,Cooling Tower,Mixer,Hopper Dryer,water pump,robot, dehumidifier etc.if you need any other equipment,please feel freely contact with us.Thanks very much.
Click here to send us a message.
4.Key Components on Haijia Injection molding machine
Clamping unit,injection unit,electric system,valves,color screen,T slot platen
Techmation controller etc.
Click here to send us a message.
5.Workshop of Injection Molding Machine
CNC Drilling machine, Boring machine,lathe, Grinding machine etc. Welcome you to got to visit our factory.
Click here to send us a message.
6. Haijiang attend the Chinaplas exhibition
Every year,we will attend the plas show in the world. Once you get to chinaplas,please call us. we can meeting on our booth.
Click here to send us a message.
7.Quality Control for EPS injection Molding Machine
Our factory photos, hope can let you know more about us. standard factory construction.We have quality department. every machine before sending out,must be inspect by 5 step.Try to make sure no problem after machine get to customer's workshop.
Click here to send us a message.
8.Haijiang Culture
Make our stuff feel happy,let them find a feeling like stay at home.it is our job,every year,we will have activies,touring,c competition, Mountain climbing.Here,we are big family.we hope each other,make happy each other.we are team,we are family.
Click here to send us a message.
9.CE ,ISO9001-2020 and SGS Certificate for Injection Molding Machine
You are USA people or European people or Africa, no problem. we can offer sending the machine to you. because we have CE,ISO9001 ect.
Click here to send us a message.
FAQ
Q1. What is the warranty for the injection molding machine
A1:Total 18 month,Included machine platen,base,injection unit,clamping unit.
Q2:Can you sending engineer to oversea install machine and trainning customer's workers.
A1: Yes,We will send engineer to customer factory install the machine or trainning customer's workers. in one week,total free.
After one week, 50$ per day
Q3:How Many spare parts you will prepare for customer?
A3: Spare parts included: mould clamp, long and short nozzle,heating band,Wrench,Switch,Thermocouple,Operation manual
Tool box,Lubricate Oil,Sealing,Filter etc.
Q4:Computer sytem,Except English, can you change other language,say: French,Spanish,Arabic,Russian.
A1:Yes,when you place order,please tell us the language which you required. Standard one with English,Japanese,Chinese,Korea.
Q5:Can you change the power source for us? Say:we need 3 Phase 220V 60HZ
A5: When you place order,please write clearly.Then we will change the electric system for you.
Q6:If i Need Green Color machine,can you do it for us?
Q7:
Yes,please give us the color sample.So we can do it for you.
