Quick Details
-
Brand Name:
-
SNTOOM
-
Model Number:
-
STXL
-
Max. Current:
-
10
-
Product name:
-
PULL CORD SWITCH
-
Color:
-
Yellow
-
Rated current:
-
10A
-
Rated voltage:
-
380vac
-
Type:
-
Manual automatic reset
-
Material:
-
Aluminum Alloy
-
Application:
-
Industrial
-
Protection degree:
-
IP67
-
ANY QUESTION:
-
Send
-
Condition:
-
100% Original
-
Certification:
-
CE/ISO/IEC
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
380VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SNTOOM
-
Model Number:
-
STXL
-
Max. Current:
-
10
-
Product name:
-
PULL CORD SWITCH
-
Color:
-
Yellow
-
Rated current:
-
10A
-
Rated voltage:
-
380vac
-
Type:
-
Manual automatic reset
-
Material:
-
Aluminum Alloy
-
Application:
-
Industrial
-
Protection degree:
-
IP67
-
ANY QUESTION:
-
Send
-
Condition:
-
100% Original
-
Certification:
-
CE/ISO/IEC
Product Description
INTRODUCTION
* Aluminum alloy
The shell is made of aluminum alloy die-casting, which is anti-corrosion and moisture-proof and durable.
* Good sealing
Good sealing performance, good waterproof and moisture-proof function
* Waterproof connector
Material upgrade, the wiring is generally made of PVC, this section uses pure copper material, more performance, corrosion resistance and moisture.
* Aluminum alloy
The shell is made of aluminum alloy die-casting, which is anti-corrosion and moisture-proof and durable.
* Good sealing
Good sealing performance, good waterproof and moisture-proof function
* Waterproof connector
Material upgrade, the wiring is generally made of PVC, this section uses pure copper material, more performance, corrosion resistance and moisture.
Specification
|
Product name
|
Pull Cord Rope Switch
|
|
Action angle
|
30°
|
|
Extreme angle
|
60°
|
|
Ambient temperature
|
-30℃ ~ 75℃
|
|
Reset method
|
Automatic Manual reset
|
|
Action force
|
10KG
|
|
Contact capacity
|
AC380V; 10A
|
|
Relative humidity
|
>=85%
|
|
Number of contacts
|
2NO,1NC
|
I
nstallation method:
a) The switch is installed on the rack fixing bracket smoothly.
b) Tie the steel wire rope to the pull rings at both ends, and the rope length on each side should not exceed 40 meters (if there is a slope, it should be shortened to 30 meters).
c) The pulling force should be appropriate to ensure the reliable reset of the switch.
d) The steel wire rope is set along the parallel direction of the tape, and a lifting ring is added every 3 meters.
