Quick Details
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Variable frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Gree
-
Model Number:
-
fairy
-
Capacity (btu):
-
24000
-
COP:
-
-
-
Power (W):
-
2068
-
Voltage (V):
-
220-240V
-
Maximum Airflow Rate:
-
1200㎡/h
-
Featured Function:
-
self diagnosis
-
Recommended Room Size（square feet）:
-
500
-
Product Name:
-
wall type split air conditioner
-
Refrigerant:
-
R410a
-
Cooling capacity:
-
2.2-7.1kw
-
Heating capacity:
-
2.5-7.5kw
-
NOISE LEVEL:
-
35 DB
-
Function:
-
Cooling\Heating
-
Certification:
-
ce
Quick Details
-
Warranty:
-
5 years
-
Type:
-
Split Wall Mounted Air Conditioners
-
Application:
-
Hotel, Car, Garage, RV, Commercial, Household
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Variable frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Gree
-
Model Number:
-
fairy
-
Capacity (btu):
-
24000
-
COP:
-
-
-
Power (W):
-
2068
-
Voltage (V):
-
220-240V
-
Maximum Airflow Rate:
-
1200㎡/h
-
Featured Function:
-
self diagnosis
-
Recommended Room Size（square feet）:
-
500
-
Product Name:
-
wall type split air conditioner
-
Refrigerant:
-
R410a
-
Cooling capacity:
-
2.2-7.1kw
-
Heating capacity:
-
2.5-7.5kw
-
NOISE LEVEL:
-
35 DB
-
Function:
-
Cooling\Heating
-
Certification:
-
ce
Product Details
|
MODEL
|
GWH09QB-K3DNB6B
|
GWH12QC-K3DNB6B
|
GWH18QD-K3DNB6B
|
GWH24QE-K3DNB6B
|
||||
|
Function
|
Cooling/Heating
|
Cooling/Heating
|
Cooling/Heating
|
Cooling/Heating
|
||||
|
Capacity-Cooling/(Btu/h)
|
9042
|
12283.2
|
18000
|
24500
|
||||
|
Capacity-Heating/(Btu/h)
|
9042
|
12965.6
|
18083
|
23000
|
||||
|
EER(W/W)
|
3.1
|
3.098
|
3.3
|
3.41
|
||||
|
COP(W/W)
|
3.8
|
3.8
|
3.66
|
3.61
|
||||
|
Power Supply
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
||||
|
Rated Input/W
|
1450
|
1650
|
1900
|
3100
|
||||
|
Rated Current/A
|
6.3
|
7
|
8.64
|
13
|
||||
|
Refrigerant
|
R410a
|
|
|
|
||||
|
Airflow Volume/(m³/h)
|
570/520/480/410/340/300/280
|
680/620/560/490/450/420/390
|
910/850/780/740/700/650/610
|
1300/1150/1100/950/870/800/700
|
||||
|
Dehumidifying Volume/(L/h)
|
0.8
|
1.6
|
1.8
|
2
|
||||
|
Application/㎡
|
12-18
|
16-24
|
23-34
|
27-42
|
||||
|
Indoor Unit
|
|
|
|
|
||||
|
Sound Pressure Level-Indoor/(dB)
|
40/37/35/33/29/25/24
|
41/37/36/33/31/30/28
|
42/38/36/33/31/30/27
|
48/45/43/40/37/35/31
|
||||
|
Outline Dimension-W*H*D/mm
|
779*260*185
|
825*293*196
|
982*311*221
|
1075*333*246
|
||||
|
Package Dimension-W*H*D/mm
|
828*332*258
|
875*365*268
|
1044*385*297
|
1133*414*333
|
||||
|
Net Weight/Gross Weight/kg
|
8.5/10
|
10/12
|
14/16.5
|
17/20
|
||||
|
Outdoor Unit
|
|
|
|
|
||||
|
Sound Pressure Level/dB
|
50
|
52
|
55
|
55
|
||||
|
Outline Dimension-W*H*D/mm
|
782*540*320
|
732*555*330
|
732*550*330
|
912*646*373
|
||||
|
Package Dimension-W*H*D/mm
|
823*358*595
|
794*376*615
|
794*376*615
|
963*411*700
|
||||
|
Net Weight/Gross Weight/kg
|
26/28.5
|
24.5/27
|
26.5/29
|
41/44
|
||||
|
Loading Quantity-40'GP/sets
|
246
|
213
|
195
|
131
|
||||
|
Loading Quantity-40'HQ/sets
|
284
|
259
|
227
|
150
|
||||
