Quick Details
-
Color:
-
Full Color
-
Panel Size:
-
320*320mm X 3, 320*320mm X 3
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
M-WA
-
Brightness:
-
≥4500cd/㎡, ≥4500cd/㎡, 4500-5000cd/sqm
-
pixel density:
-
4mm, 4mm
-
Contrast Ratio:
-
3000:1, 3000:1
-
Lifespan (hours):
-
80000hours, 80000hours
-
IP Rating:
-
IP55, IP55
-
Resolution:
-
384*128dots/side
-
View Angle（H/V）:
-
140°/140°, 140°/140°
-
Certificate:
-
CE/CCC/FCC/ROHS/ISO9001
-
Refresh rate:
-
3840Hz
-
Display size:
-
320*320mm X 3pcs
-
Max power consumption:
-
100W
-
Average power consumption:
-
15W
-
Waterproof:
-
IP65
-
4G:
-
Yes
-
Wifi:
-
Yes
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
Mepro
-
Color:
-
Full Color
-
Panel Size:
-
320*320mm X 3, 320*320mm X 3
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
M-WA
-
Brightness:
-
≥4500cd/㎡, ≥4500cd/㎡, 4500-5000cd/sqm
-
pixel density:
-
4mm, 4mm
-
Contrast Ratio:
-
3000:1, 3000:1
-
Lifespan (hours):
-
80000hours, 80000hours
-
IP Rating:
-
IP55, IP55
-
Resolution:
-
384*128dots/side
-
View Angle（H/V）:
-
140°/140°, 140°/140°
-
Certificate:
-
CE/CCC/FCC/ROHS/ISO9001
-
Refresh rate:
-
3840Hz
-
Display size:
-
320*320mm X 3pcs
-
Max power consumption:
-
100W
-
Average power consumption:
-
15W
-
Waterproof:
-
IP65
-
4G:
-
Yes
-
Wifi:
-
Yes
Products Description
Technical Parameter
|
Pixel Pitch(mm)
|
2.5
|
3.076
|
4
|
|
Full screen Resolution(dot)
|
128*128 X 3
|
104*104 X 3
|
80*96 X 3
|
|
Display Size(mm)
|
320*320 X 3
|
320*320 X 3
|
320*384mmX3
|
|
Cabinet Size(mm)
|
L500*H500*W500
|
L540*H500*W520
|
L500*H500*W500
|
|
Ave.consumption
|
70W
|
70W
|
70W
|
|
Brightness(CD/㎡)
|
≥4500
|
≥4500
|
≥4500
|
|
Refresh Rate(Hz)
|
1920
|
1920
|
1920
|
|
Operation Power
|
DC12V
|
DC12V
|
DC12V
|
|
Control Mode
|
4G/WIFI
|
4G/WIFI
|
4G/WIFI
|
|
Viewing Angle (H/V)
|
140°/140°
|
140°/140°
|
140°/140°
|
|
Brightness Adjustment
|
0-255 levels adjustable
|
0-255 levels adjustable
|
0-255 levels adjustable
|
|
Drive Mode
|
1/16S
|
1/16S
|
1/16S
|
|
Operating Temperature
|
-30℃~+70℃
|
-30℃~+70℃
|
-30℃~+70℃
|
|
Cabinet Weight
|
16 kg/ set
|
16 kg/ set
|
15 kg/ set
|
