Quick Details
-
Model Number:
-
W-110B&W-215
-
Dimension:
-
280*440*455mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W RMS
-
Format:
-
NA
-
Type:
-
line array system
-
Frequency Response:
-
65Hz-18KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Power handling:
-
LF 350W(RMS)1400W(PEAK)
-
Sensitivity:
-
LF 101dB(1W@1M)
-
Enclosure:
-
Birch Plywood
-
Dimensions:
-
280*440*455mm(W*H*D)
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-110B&W-215
-
Dimension:
-
280*440*455mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W RMS
-
Format:
-
NA
-
Type:
-
line array system
-
Frequency Response:
-
65Hz-18KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Power handling:
-
LF 350W(RMS)1400W(PEAK)
-
Sensitivity:
-
LF 101dB(1W@1M)
-
Enclosure:
-
Birch Plywood
-
Dimensions:
-
280*440*455mm(W*H*D)
Product Description
|
Model
|
W-110B&W-110BP
W-215&W-215P |
|
Type
|
Two-way line array system
Line array subwoofer system(W-215&W-215P) |
|
Frequency Response
|
65Hz-18KHz±3dB
40Hz-300Hz±3dB(W-215&W-215P) |
|
Power handling
|
LF 350W(RMS)1400W(PEAK)
HF 110W(RMS)440W(PEAK) 1600W(RMS)6400W(PEAK)(W-215&W-215P) |
|
Sensitivity
|
LF 101dB(1W@1M)
HF 103dB(1W@1M) 101dB(1W/1M)(W-215&W-215P) |
|
Max SPL
|
LF 128dB(PEAK/1M)
HF 131dB(PEAK/1M) 133dB(1W/1M)(W-215&W-215P) |
|
Drivers
|
LF 1×10"(260mm)neodymium woofer 75mm(3in)coil
HF 1×3" neodymium compression driver with75mm titanium diaphragm 2×15"(385mm)woofer with 100mm (4in) coil(W-215&W-215P) |
|
Nominal impedance
|
16 ohm
4 ohm(W-215&W-215P) |
|
Coverage
|
110°H×10°V
|
|
Connectors
|
2×NL4MP speakon
|
|
Enclosure
|
Birch Plywood
|
|
Dimensions
|
280×440×455mm(W×H×D)
440×880×800mm(W×H×D)(W-215&W-215P) |
|
Packing Dimensions
|
350×520×525mm(W×H×D)/0.1cbm
510×955×880mm(W×H×D)/0.4cbm(W-215&W-215P) |
|
Net weight
|
18kg(W-110B)/20kg(W-110BP)
73kg(W-215)/77kg(W-215P)(W-215&W-215P) |
|
Gross weight
|
21.5kg(W-110B)/23.5kg(W-110BP)
78kg(W-215)/82kg(W-215P)(W-215&W-215P) |
