Quick Details
-
Panel Dimensions:
-
customized
-
Panel Efficiency:
-
200W
-
Product name:
-
BIPV
-
Transparency:
-
10%~70%
-
Thickness of the glass:
-
3.2mm/5mm/6mm/8mm/10mm/12mm
-
Solar cell:
-
166*166mm
-
Connector:
-
MC4 Compatible Connector
-
Junction Box:
-
IP67 Rated Waterproof
-
Cable:
-
4mm2 Customized
-
Color:
-
Transparent
-
Frame:
-
Anodized Aluminium Alloy
-
Cell Type:
-
mono
Quick Details
-
Brand Name:
-
Reza
-
Model Number:
-
RZ200-BI
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
customized
-
Panel Efficiency:
-
200W
-
Product name:
-
BIPV
-
Transparency:
-
10%~70%
-
Thickness of the glass:
-
3.2mm/5mm/6mm/8mm/10mm/12mm
-
Solar cell:
-
166*166mm
-
Connector:
-
MC4 Compatible Connector
-
Junction Box:
-
IP67 Rated Waterproof
-
Cable:
-
4mm2 Customized
-
Color:
-
Transparent
-
Frame:
-
Anodized Aluminium Alloy
-
Cell Type:
-
mono
Specification
|
Model Type
|
|
YS200M-BI
|
|
YS300M-BI
|
YS400M-BI
|
|||||
|
Rated Maximum Power at STC
|
|
200W
|
|
300W
|
400W
|
|||||
|
Maximum Power Voltage (Vmp)
|
|
28.5V
|
|
33.2V
|
34.82V
|
|||||
|
Maximum Power Current (Imp)
|
|
7.02A
|
|
9.03A
|
11.49A
|
|||||
|
Open Circuit Voltage ( Voc)
|
|
35.63V
|
|
41.5V
|
43.53V
|
|||||
|
Short Circuit Current (Isc)
|
|
7.51A
|
|
9.69A
|
12.64A
|
|||||
|
Module Efficiency
|
|
14.90%
|
|
18.44%
|
21.98%
|
|||||
|
Working Conditions&Working Conditions
|
|
|
|
|
|
|||||
|
Glass Thickness
|
|
2mm 4mm 6mm 8mm 10mm 12mm
|
|
|
|
|||||
|
Transmittance
|
|
10% 20% 30% 40% 50% 60% 70% 80%
|
|
|
|
|||||
|
Operating Temperature
|
|
-40°c~+85°c
|
|
|
|
|||||
|
Maximum System Voltage
|
|
DC 1000V(IEC) / 1500V(IEC)
|
|
|
|
|||||
|
Maximum Series Fuse
|
|
25A
|
|
|
|
|||||
|
Power Tolerance
|
|
0~+5W
|
|
|
|
|||||
|
Temperature Coefficient of Pmax
|
|
-0.35%/°c
|
|
|
|
|||||
|
Temperature Coefficient of Voc
|
|
-0.29%/°c
|
|
|
|
|||||
|
Temperature Coefficient of Isc
|
|
+0.048%/°c
|
|
|
|
|||||
|
STC(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
|
|
|
|
|
|
|||||
|
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S
|
|
|
|
|
|
|||||
Product Description
Solar Cells
Crystalline silicon cells 158.75*158.75mm ，166*166mm ,182*182mm 210*210mm can be selected high power, guaranteed power generation
Transmittance
The greater the light transmittance, the better the lighting in the house,Transmittance is generally between 10% and 80%
Component structure
The following is a schematic diagram of the conventional structure
Glass processing thickness
While ensuring the aesthetics, it can also protect the cells.Now the thickness we do is generally between 4mm-12mm
Glass color
For some BIPV that is used in buildings and needs color, colored glass can be selected
Glass color
For some BIPV that is used in buildings and needs color, colored glass can be selected
Shape
Sizes can be customized，the following are several common shapes
Our Projects
Factory
Packing & Payment
|
Payment Term
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment |
||
|
|
|
FOB
|
|
||
|
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L |
||
|
|
|
CIF
|
|
||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
||
|
|
Paypal
|
Amount lower than 5000usd
|
|
||
|
|
West Union
|
|
|
||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
||
