The input terminal interface current source, the second-wire system, the three-wire transmitter, and the internal use of high-efficiency electromagnet isolation technology, input, output, and power supply are isolated from each other, high-precision, high linearity, low temperature drift.
- Product Details
- {{item.text}}
Quick Details
-
Appearance color:
-
green
-
Material Science:
-
ABS plastic
-
accuracy:
-
0.1%FS
-
Power Supply:
-
DC24V
-
power:
-
1W
-
size:
-
116*105*13mm
-
Product performance:
-
Fast response, anti-interference and lightning protection
-
Installation mode:
-
35mm guide rail
-
load:
-
≤500Ω
-
response time:
-
≤10ms
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
DOCHQH henandongchuan
-
Model Number:
-
DQ703CB
-
Appearance color:
-
green
-
Material Science:
-
ABS plastic
-
accuracy:
-
0.1%FS
-
Power Supply:
-
DC24V
-
power:
-
1W
-
size:
-
116*105*13mm
-
Product performance:
-
Fast response, anti-interference and lightning protection
-
Installation mode:
-
35mm guide rail
-
load:
-
≤500Ω
-
response time:
-
≤10ms
Product selection
Product introduction
DC24V power, provide quarantine distribution power supply for the transmitter on site, and transmit the current signal generated by the transmitter from the field quarantine to the control room, PLC, DCS, etc
Model selection
size
|
model
|
Input signal
|
output
|
Power Supply
|
accuracy
|
|
DQ703CB-111
|
Input1 4-20mA
|
1 OUTPUT 4-20mA
|
DC24V
|
0.1%FS
|
|
DQ703CB-211
|
Input1 4-20mA
|
2 output 4-20mA
|
DC24V
|
0.1%FS
|
|
DQ703CB-146
|
1 input 0-10V
|
1 output 0-10V
|
DC24V
|
0.1%FS
|
|
DQ703CB-116
|
1 input 4-20mA
|
1 output 0-10V
|
DC24V
|
0.1%FS
|
|
DQ703CB-141
|
1 input 0-10V
|
1 output 4-20mA
|
DC24V
|
0.1%FS
|
|
Accuracy
|
0.1% FS
|
|
Load
|
≤ 500 Ω
|
|
Power frequency withstand voltage
|
ac2.5kv/min.1ma
|
|
Size
|
116* 105 * 13MM
|
|
Operating frequency
|
50Hz / 60Hz
|
|
Service temperature
|
- 20 ~ 55 ℃
|
|
Power
|
2W
|
|
Power supply
|
DC24V、
|
|
Response time
|
≤ 10ms
|
|
Temperature drift
|
1500rpm / ℃
|
|
Applicable field equipment
|
current source, two-wire system and three wire system
|
Details Images
wiring diagram
