Advantages of our sovlent-less laminating machine:
1. Coating amount control accurate, easy adjust
2.High Laminating Quality
3.Highly User-friendly
4.Machine safety is good, stable and reliable;
5. Operation easy to use;
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
5100x3600x2500MM
-
Weight:
-
14000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Speed:
-
500m/min
-
Machine body thickness:
-
80mm
-
After Warranty Service:
-
Field maintenance and repair service
-
Local Service Location:
-
None
-
Certification:
-
CE Certificate
-
Marketing Type:
-
Hot Product 2019
Quick Details
-
Voltage:
-
380V, 3phases
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SEN
-
Dimension(L*W*H):
-
5100x3600x2500MM
-
Weight:
-
14000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Speed:
-
500m/min
-
Machine body thickness:
-
80mm
-
After Warranty Service:
-
Field maintenance and repair service
-
Local Service Location:
-
None
-
Certification:
-
CE Certificate
-
Marketing Type:
-
Hot Product 2019
Product Description
SEN-1050A/1350A Solventless Laminating Machine
|
Printing Material’s way
|
Left to right
|
|
|
Mechanical Speed
|
580m/min
|
|
|
Max Laminating Speed
|
500m/min
|
|
|
(The maximum production speed will be affected by the quality and properties of the substrate and binder used)
|
|
|
|
Max coating width
|
1050mm
|
|
|
Max roll width
|
1050mm
|
|
|
Min roll width
|
400mm
|
|
|
Unwind paper core
|
3’’=76mm and 6’’=152mm
|
|
|
Rewind paper core
|
3’’=76mm and 6’’=152mm
|
|
|
Unwind tension range
|
3--40kg(400N)
|
|
|
Rewind tension range
|
4--55kg(550N)
|
|
|
Rewind tape tension setting range
|
100%--60%
|
|
|
Max roll weight
|
1,000kg
|
|
|
Coating range
|
0.8-3g/sm
|
|
|
Dimension
|
5100x3600x2500MM
|
|
|
Power
|
53KW
|
|
|
Weight
|
14000KG
|
|
|
Machine color
|
Ivory white
|
|
