Quick Details
-
Color:
-
full color
-
Panel Size:
-
500x1000/500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P1.9/P2.6/P2.9/P3.9/P4.8
-
use:
-
Stage Events, Wedding, Conference, Church
-
Specification:
-
Stage led wall
-
Brightness:
-
3500nits, >1200cd/sqm
-
pixel density:
-
65410dots/sqm
-
Contrast Ratio:
-
16:1
-
Color Depth:
-
16
-
Lifespan (hours):
-
100000
-
IP Rating:
-
65
-
HS Code:
-
8531200000
-
Resolution:
-
128*256
-
View Angle（H/V）:
-
140
-
Product Name:
-
Stage LED Screen
-
Certificate:
-
CE ROHS FCC CCC ISO9001
-
Module size:
-
250mmx250mm
-
Usage:
-
For Concert/Wedding/Conference
-
Refresh rate:
-
3840Hz
-
Installation:
-
Groound / Hanging Support
-
Screen Dimension:
-
500mm x 500mm/ 500mm x 1000mm
-
Viewing angle:
-
160° H / 160°V
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LED
-
Brand Name:
-
OEM
-
Color:
-
full color
-
Panel Size:
-
500x1000/500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P1.9/P2.6/P2.9/P3.9/P4.8
-
use:
-
Stage Events, Wedding, Conference, Church
-
Specification:
-
Stage led wall
-
Brightness:
-
3500nits, >1200cd/sqm
-
pixel density:
-
65410dots/sqm
-
Contrast Ratio:
-
16:1
-
Color Depth:
-
16
-
Lifespan (hours):
-
100000
-
IP Rating:
-
65
-
HS Code:
-
8531200000
-
Resolution:
-
128*256
-
View Angle（H/V）:
-
140
-
Product Name:
-
Stage LED Screen
-
Certificate:
-
CE ROHS FCC CCC ISO9001
-
Module size:
-
250mmx250mm
-
Usage:
-
For Concert/Wedding/Conference
-
Refresh rate:
-
3840Hz
-
Installation:
-
Groound / Hanging Support
-
Screen Dimension:
-
500mm x 500mm/ 500mm x 1000mm
-
Viewing angle:
-
160° H / 160°V
Product Description
Specification
|
Indoor&Outdoor H-series Specification
|
|
|
|
|
|
|||||
|
Model
|
P1.9
|
P2.6
|
P2.9
|
P3.9
|
P4.8
|
|||||
|
Pixel Pitch
|
1.953mm
|
2.604mm
|
2.976mm
|
3.91mm
|
4.81mm
|
|||||
|
Module size
|
250mm
|
250mm
|
250mm
|
250mm
|
250mm
|
|||||
|
Module Resolution
|
128x128px
|
96x96px
|
84x84px
|
64x64px
|
54x54px
|
|||||
|
Cabinet size
|
500mm(h) x 500mm(w) or 1000mm(h) x 500mm(w)
|
|
|
|
|
|||||
|
Cabinet Resolution
|
256 x 256 px
|
192 x 192 px
|
168 x 168px
|
128 x 128px
|
104 x 104px
|
|||||
|
Cabinet Structure
|
Die casting Aluminum Cabinet
|
|
|
|
|
|||||
|
Cabinet weight
|
7kg
|
|
|
|
|
|||||
|
Pixels Density
|
262144 pixels/sqm
|
147456 pixels/sqm
|
112896 pixels/sqm
|
65536 pixels/sqm
|
43264 pixels/sqm
|
|||||
|
LED Encapsulation Type
|
SMD1515
|
SMD1515
|
SMD2020
|
SMD2020
|
SMD2020
|
|||||
|
Pixel Configuration
|
1R1B1G
|
1R1B1G
|
1R1B1G
|
1R1B1G
|
1R1B1G
|
|||||
|
Brightness
|
Indoor >800nits outdoor >3500nits
|
Indoor >800nits outdoor >3500nits
|
Indoor >800nits outdoor >3500nits
|
Indoor >800nits outdoor >3500nits
|
Indoor >800nits outdoor >3500nits
|
|||||
|
Drive Mode
|
1/32 scan
|
1/32 scan
|
1/28scan
|
1/16scan
|
1/13scan
|
|||||
|
Viewing Angle
|
Horizontal 160° ; Vertical 160°
|
|
|
|
|
|||||
|
Data Refresh Rate
|
>3840hz
|
>3840hz
|
>3840hz
|
>3840hz
|
>3840hz
|
|||||
|
Input power
|
AC 110/220v
|
AC 110/220v
|
AC 110/220v
|
AC 110/220v
|
AC 110/220v
|
|||||
|
Power Consumption
|
Max:600w/sqm; Average: 300w/sqm
|
|
|
|
|
|||||
|
Ambient Temperature
|
-40℃～+60℃
|
|
|
|
|
|||||
|
Screen Life Span
|
≥100000 hours
|
|
|
|
|
|||||
|
Ingress Protection
|
Indoor IP45 / Outdoor IP65
|
|
|
|
|
|||||
Packing & Delivery
LED Screen Stage Flight case / Wooden Carton
