15W 110V 220v High Torque Low Rpm Electric Variable Speed Control AC Gear Motor With Speed Controller

15W 110V 220v High Torque Low Rpm Electric Variable Speed Control AC Gear Motor With Speed Controller

FOB Reference Price: Get Latest Price

≥5 Sets

US $49

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: 3IK15GN

Frequency:: 50HZ/60HZ

Product Name:: AC induction motor

Power:: 15w (6w-750w)

Torque:: 90mN.m

Rated Speed:: 1450r/min

Motor Frame Size:: 104mm

Pinion Shaft:: GN Type

Current:: 0.350A

Capacitor:: 6.0uF

Motor Type:: Induction motor

Certification:: Ce

Quick Details

AC Voltage:: 110v-380v

Place of Origin:: Henan, China

Brand Name:: LUNYEE

Model Number:: 3IK15GN

Frequency:: 50HZ/60HZ

Product Name:: AC induction motor

Power:: 15w (6w-750w)

Torque:: 90mN.m

Rated Speed:: 1450r/min

Motor Frame Size:: 104mm

Pinion Shaft:: GN Type

Current:: 0.350A

Capacitor:: 6.0uF

Motor Type:: Induction motor

Certification:: Ce

Product Description

Specification

we can custom parameters and shaft size, please contact us

1. When the motor is approved under various safety standards, the model name on the nameplate is the approved model name. Note:
2. “-A” it means the voltage 110V, the assembly capacitor value it is according the label.

Motor Type Lead Wire Type			Output power W	Voltage V	Frequency Hz	Current A	Starting torque mN.m	Raed Torque mN.m	Rated speed r/min	Capacitor μF

Pinion Shaft	Round Shaft
3IK15GN-C	3IK15A-C	15	1ph220	50	0.18	90	125	1250	1.2
											1ph230		0.2
3RK15GN-C	3RK15A-C	15	1ph220	60	0.16	65	105	1550
										1ph230		0.15	70
