Quick Details
-
Brand Name:
-
Xingtailong,OEM
-
Purity:
-
95%99%
-
Product Name:
-
Alumina Ceramic Disc Ceramic Cartridge Tap Ceramic Disc Insulation
-
Color:
-
White/Black
-
Surface Treatment:
-
Polished
-
Category:
-
Ceramic Disc
-
Materical:
-
Alumina
-
Maximum Use Temperature:
-
More Than 1500
-
Compressive Strenght:
-
2200-3000
-
Ceramic Disc Application:
-
Single-handle Mixers
-
Used:
-
Alumina/Ceramic Disc/Cartridge
Quick Details
-
Material:
-
Alumina Ceramic
-
Place of Origin:
-
Hunan, China
-
Model Number:
-
Customize
-
Brand Name:
-
Xingtailong,OEM
-
Purity:
-
95%99%
-
Product Name:
-
Alumina Ceramic Disc Ceramic Cartridge Tap Ceramic Disc Insulation
-
Color:
-
White/Black
-
Surface Treatment:
-
Polished
-
Category:
-
Ceramic Disc
-
Materical:
-
Alumina
-
Maximum Use Temperature:
-
More Than 1500
-
Compressive Strenght:
-
2200-3000
-
Ceramic Disc Application:
-
Single-handle Mixers
-
Used:
-
Alumina/Ceramic Disc/Cartridge
XTL sintyron Insulator High Purity Porous 99.5% Alumina Ceramic Valve Plate
| Item | Test condition | Unit | White alumina ceramic | Black alumina ceramic | |||||
| 80% | 92% | 95% | 96% | 99% | 90% | 91% | |||
| Main ingredients and content | Wt% | 80% al2o3 | 92% al2o3 | 95% al2o3 | 96% al2o3 | 99% al2o3 | 90% al2o3 | 91% al2o3 | |
| Bulk density | g/cm ² | 3.3 | 3.6 | 3.65 | 3.8 | 3.89 | 3.6 | 3.9 | |
| Flexural strength | MPa | 220 | 320 | 310 | 280 | 490 | 280 | 210 | |
| Coefficient of linear expansion | 200-800 °C | 7.6 | 7.5 | 7.2 | 7.6 | 7.6 | 7.3 | 7.7 | |
| Thermal conductivity | 300 °C | w/(mk) | 17 | 17 | 17 | 21 | 37 | 17 | 17 |
| Volume resistance | 100 °C | cm | |||||||
| Dielectric constant | IMHZ °C20 | 8 | 8.5 | 8.6 | 9.4 | 10.6 | 7.9 | ||
| Dielectric loss | 80 °C | 4-8 | 2-2.5 | 2-2.1 | 2-3 | 2-3 | |||
| Angle tangent value | After dampness | 1.5 | 2-2.3 | 2.2-3.5 | 2.2-3.5 | ||||
ceramic valve:
1,90%-95% Alumina Ceramic valve.
2.High intension.
3.Solid-resist,alkali-resistence.
4,Reasonable price.
Specification of the tap ceramic disc:
- OD: 11.5mm---40mm ceramic discs
- The frictional times is 300, 000 to 500, 000
- Rigidity is 84~86 HRA.
- The thickness tolerance is less than 0.05mm, the diameter tolerance is less than 0.05mm.
