Quick Details
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
Yuchai
-
Weight:
-
900
-
Rated power/speed:
-
400/230
-
Model:
-
ZC28GF1
-
Prime Power:
-
50 KW
-
Standby Power:
-
55KW
-
Voltage:
-
400/230V
-
Current:
-
90A
-
Speed:
-
1500r/min
-
Frequency:
-
50Hz
-
Rated power factor:
-
0.8
-
Voltage recovery time:
-
≤1
-
Start mode:
-
Dc 24V electric starting
Quick Details
-
Displacement:
-
Other
-
Emission Standard:
-
Other
-
Power:
-
50KW
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
Yuchai
-
Weight:
-
900
-
Rated power/speed:
-
400/230
-
Model:
-
ZC28GF1
-
Prime Power:
-
50 KW
-
Standby Power:
-
55KW
-
Voltage:
-
400/230V
-
Current:
-
90A
-
Speed:
-
1500r/min
-
Frequency:
-
50Hz
-
Rated power factor:
-
0.8
-
Voltage recovery time:
-
≤1
-
Start mode:
-
Dc 24V electric starting
Products Description
Specifications
|
model
|
|
ZC70GF1
|
|
|
Prime Power（kW）
|
|
50
|
|
|
Standby Power(KW)
|
|
55
|
|
|
voltage （V）
|
|
400/230
|
|
|
Current （A）
|
|
90
|
|
|
Speed （r/min）
|
|
1500
|
|
|
Frequency（Hz）
|
|
50
|
|
|
Rated power factor
|
|
0.8
|
|
|
The generating set consumes electricity L/h
|
|
60
|
|
|
Steady state voltage deviation （%）
|
|
≤±2.5
|
|
|
Transient voltage deviation （%）
|
100%The sharp reduction power
|
≤+25
|
|
|
|
Sharp increase power
|
≤－20
|
|
|
Voltage recovery time （S）
|
|
≤1
|
|
|
Voltage unbalance degree（%）
|
|
≤1
|
|
|
Voltage modulation （%）
|
|
0.3
|
|
|
Frequency drop（%）
|
|
≤5
|
|
|
Steady state frequency band （%）
|
|
≤1.5
|
|
|
The relative frequency adjusts the drop range (%)
|
|
≥7.5
|
|
|
Relative frequency setting range of rise (%)
|
|
≥2.5
|
|
|
Transient frequency deviation （%）
|
100%sharp reduction power
|
≤+12
|
|
|
|
Sharp increase power
|
≤－10
|
|
|
Frequency recovery time （S）
|
|
≤5
|
|
|
Relative frequency tolerance band %
|
|
2
|
|
|
Phase and connection
|
|
Three phase four wire
|
|
|
Start mode
|
|
Dc 24V electric starting
|
|
|
voltage regulating mode
|
|
Automatic
|
|
|
Cooling
|
|
Closed, water cooled
|
|
|
Excitation way
|
|
Brushless (AVR)
|
|
|
ENGINE MODLE
|
|
YUCHA I YC4D90-D34
|
|
|
ALTERNATOR MODLE
|
|
EVOTEC TCU228C
|
|
|
WEIGHT kg
|
|
900
|
|
|
SIZE(L*W*H)MM
|
|
1830×750×1100
|
|
