Quick Details
-
Power (kW):
-
45
-
Weight (KG):
-
1400 kg
Quick Details
-
Place of Origin:
-
China
-
Voltage:
-
380/415/440/460v
-
Year:
-
2023
-
Power (kW):
-
45
-
Weight (KG):
-
1400 kg
| Model | XY-3R230x630 | XY-3R252x720 | XY-3R360x1120 | XY-3R400x1200 | XY-3R450x1400 | XY-3R550x1600 | XY-3R610x1730 | XY-3R710x1800 | XY-3R710x2130 |
| Roll dia.(mm) | 230 | 252 | 360 | 400 | 450 | 550 | 610 | 710 | 710 |
| Roll working length(mm) | 630 | 720 | 1120 | 1200 | 1400 | 1600 | 1730 | 1800 | 2130 |
| Roll ratio |
1:1:1 1:1.2:1 |
1:1:1 |
1:1:1 0.733:1:1 0.733:1:0.733 |
1:1:1 1:1.383:1.383 1:1.383:1 |
1:1:1 1:1.5:1 |
1:1:1 1:1.5:1 |
1:1:1 1:1.4:1 |
0.5~1 | 1:1:1 |
| Middle-roll linear speed(m/min) | 0.8-8 | 2-15.9 | 3-20 | 3-26.9 | 2.62-26.2 | 3-30 | 5.4-54 | 4-40 | 8-50 |
| Ajusting nip range(mm) | 0-7 | 0-10 | 0-10 | 0-10 | 0-10 | 0-12 | 0-20 | 0-30 | 0-20 |
| Min. calender product thickness(mm) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.15 | 0.2 | 0.15 |
| Calender product width(mm) | 500 | 550 | 920 | 1000 | 1250 | 1400 | 1500 | 1600 | 1900 |
| Motor power(kw) | 7.5 | 22 | 45 | 55 | 75 | 110 | 160 |
90kwx2 110wx1 |
185 |
| Overall size(LxWxh)(mm) | 3168x890x1830 | 3950x1720x1210 | 5500x1500x2440 | 5800x1500x2440 | 7320x2200x2900 | 6200x2300x3000 | 7010x3950x3730 | 9950x3050x4540 | 7650x4560x4080 |
| Weight(kg) | 3000 | 5500 | 10000 | 18000 | 21000 | 30000 | 42000 | 90000 | 67000 |
