Quick Details
-
Warranty:
-
25-30years
-
Brand Name:
-
Rosenpv or OEM
-
Model Number:
-
RSM550M-144HC
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm opt
-
Product name:
-
550W 600W Solar Panels
-
Cells:
-
210/182/166/158.75mm TOPCON
-
Frame:
-
Silver/Black Anodized Aluminium Alloy
-
TPT back sheet:
-
Black/White Backsheet
-
Junction Box:
-
IP68 rated, 3 diodes
-
Cable:
-
4mm² Symmetrical Lengths
-
Application:
-
Solar Energy System Projects
-
Glass:
-
3.2mm High Transmission Tempered Glass
-
System Voltage:
-
1000V/1500Vdc
-
Connector:
-
Compatible MC-4/Male/Female/Fuse
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, N-TYPE, TOPCON
-
Panel Efficiency:
-
High Efficiency 182mm
-
Warranty:
-
25-30years
-
Brand Name:
-
Rosenpv or OEM
-
Model Number:
-
RSM550M-144HC
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm opt
-
Product name:
-
550W 600W Solar Panels
-
Cells:
-
210/182/166/158.75mm TOPCON
-
Frame:
-
Silver/Black Anodized Aluminium Alloy
-
TPT back sheet:
-
Black/White Backsheet
-
Junction Box:
-
IP68 rated, 3 diodes
-
Cable:
-
4mm² Symmetrical Lengths
-
Application:
-
Solar Energy System Projects
-
Glass:
-
3.2mm High Transmission Tempered Glass
-
System Voltage:
-
1000V/1500Vdc
-
Connector:
-
Compatible MC-4/Male/Female/Fuse
Product Description
Specification
Rosen Solar, with more than 4 automatic lamination lines, are professional manufacturer of solar panels with wide power range from 5w to 300W, 450W, 550W, 600W, 650W, 680W, 700W, 800W etc. Solar panels, like PERC, N-Type TOPCON, HJT, Shingle types etc and bifacial/double glass, single glass, full black, black frame, and frameless half cell panels Mono and Polycrystaline panels, are all available in China and Europe stock. Tier 1 panels brands are available too. OEM and ODM service acceptable with the min one pallet. We have all certificates like TUV, CE, ISO, IEC etc, And technicians will provide manuals, and installation CAD SKETCH designs for roof or ground installation.
|
Model
|
RSM540-144HC
|
RSM550-144HC
|
RSM560-144HC
|
RSM570-144HC
|
RSM580-144HC
|
||||
|
Rated Maximum Power at STC
|
540W
|
550W
|
560W
|
570W
|
580W
|
||||
|
Maximum Power Voltage(Vmp/V)
|
41.64
|
41.96
|
42.28
|
42.59
|
42.89
|
||||
|
Maximum Power Current(Imp/A)
|
12.97
|
13.11
|
13.25
|
13.39
|
13.53
|
||||
|
Open Circuit Voltage(Voc/V)
|
49.60
|
49.90
|
50.20
|
50.50
|
50.80
|
||||
|
Short Circuit Current(Isc/A)
|
13.86
|
14.00
|
14.14
|
14.28
|
14.42
|
||||
|
Module Efficiency(%)
|
20.9
|
21.3
|
21.7
|
22.1
|
22.4
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000w/m², Cell Temperature 25℃, Air Mass AM1.5
|
|
|
|
|
||||
|
ELECTRICAL DATA(NOCT)
|
|
|
|
|
|
|||||
|
Maximum Power-PMAX (Wp)
|
408W
|
416W
|
424W
|
432W
|
440W
|
|||||
|
Maximum Power Voltage(Vmp/V)
|
38.99
|
39.44
|
39.90
|
40.34
|
40.78
|
|||||
|
Maximum Power Current(Imp/A)
|
10.47
|
10.55
|
10.63
|
10.72
|
10.80
|
|||||
|
Open Circuit Voltage(Voc/V)
|
46.43
|
46.68
|
46.93
|
47.19
|
47.45
|
|||||
|
Short Circuit Current(Isc/A)
|
11.09
|
11.17
|
11.25
|
11.33
|
11.41
|
|||||
|
NOCT: Irradiance at 800W/m², Ambient Temperature 20°C, Wind Speed 1m/s.
|
|
|
|
|
|
|||||
EVA
High Transmittance EVA,High GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability.
Solar Cell
5BB, 6BB, 9BB, 10BB, 12BB Available
158.75cells, 166cells, 182cells, 210cells High Efficiency Cells
Anti-Pid
158.75cells, 166cells, 182cells, 210cells High Efficiency Cells
Anti-Pid
Frame
35mm 40mm Anodized Aluminium Alloy
Black/Silver Color Optional
Black/Silver Color Optional
Junction--Box
IP 68 rated Waterproof
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Compatible MC4
MC4 Compatible /MC4 EVO2/TS4*
500N Tensile Strength
Female/Male/Fuse
500N Tensile Strength
Female/Male/Fuse
Label
Waterproof Customized Label
OEM/ODM with your Logo
Professional Silver Color
OEM/ODM with your Logo
Professional Silver Color
Packing & Delivery
Packing Details : In carton on pallet or wooden box, OEM with your logo available
Delivery Details : 5-10 working days
Delivery Details : 5-10 working days
