Optional accessories
|
Model No.
|
LRE203-R
|
LRE203-G
|
|
|
Auto level accuracy
|
Horizontal: ±15‘’ Vertical: ±20‘’
|
|
|
|
Down point accuracy
|
≤ ±1mm/1.5M
|
|
|
|
Output power
|
≤1mW, class II
|
|
|
|
Laser wave
|
635nm red beam
|
520nm green beam
|
|
|
Auto level range
|
±5°
|
|
|
|
Working range with receiver(dia)
|
800m
|
1000m
|
|
|
Remote control distance
|
25M
|
|
|
|
Slope range
|
±5°
|
|
|
|
Scanning speed
|
0.r.p.m./120r.p.m./300 r.p.m./600r.p.m. (adjustable)
|
|
|
|
Scanning width
|
0.10°.45°. 90°. 180°（adjustable）
|
|
|
|
Power
|
DC4.8-6V (N-H rechargeable battery *4)
|
|
|
|
Time in continuous use
|
15 hours (N-H rechargeable battery *4)
|
|
|
|
Working temperature
|
-20℃~+50℃
|
|
|
|
Dust proof and Splash-proof
|
IP54
|
|
|
|
Dimensions (L*W*H) MM
|
160(L)*160(W)*185(H) mm
|
|
|
|
Net weight(kgs)
|
3.0kgs include batteries
|
|
|
|
Gross weight(kgs)
|
6.0kgs
|
|
|
|
Accessories
|
remote controller*1, detector with clamp*1, rechargeable battery*4, Charger*1, instruction manual*1, plastic carrying case*1
|
|
|
