Mechanical Keyboard Test Equipment, Keyboard Switch Tester, Key Life Testing Machine

Mechanical Keyboard Test Equipment, Keyboard Switch Tester, Key Life Testing Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $3000

≥10 Sets

US $2000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model:: ASR-5619-B

Test stations:: 8 (working at the same time)

Load weights:: 8 pieces each of 50, 100, 200, 300 and 500g (optional)

Test number counter:: 0~99999999 times (can be preset, LCD display)

Test conduction times counter:: 0~999999 times

Test speed:: 5~60 times/min (knob adjustable, LCD display)

Test stroke:: 0~60mm (manually adjustable)

Adjustable range of test rod fixture:: 0~180mm

Overall dimensions (L*W*H):: 1000*400*550mm

Machine weight:: 60kg

Quick Details

Warranty:: 1 Year

Place of Origin:: Hebei, China

Brand Name:: btutest

Model:: ASR-5619-B

Test stations:: 8 (working at the same time)

Load weights:: 8 pieces each of 50, 100, 200, 300 and 500g (optional)

Test number counter:: 0~99999999 times (can be preset, LCD display)

Test conduction times counter:: 0~999999 times

Test speed:: 5~60 times/min (knob adjustable, LCD display)

Test stroke:: 0~60mm (manually adjustable)

Adjustable range of test rod fixture:: 0~180mm

Overall dimensions (L*W*H):: 1000*400*550mm

Machine weight:: 60kg

Key life test machine

The key life testing machine is suitable for mobile phones, computers, electronic dictionaries, Bluetooth headsets, car players, remote control buttons, vehicle immobilizers, fax machine buttons, MP5, MP4, MP3, key switches, tactile switches, film buttons, rubber buttons, silicone keys and other types of keys for life testing. This machine is to place the product in the test position of the corresponding station, and the key test rod simulates the service life test of the product under a certain test load, speed, stroke and times.

Specification

1. Test stations: 8 (working at the same time) 2. Load weights: 8 pieces each of 50, 100, 200, 300 and 500g (optional) 3. Test number counter: 0~99999999 times (can be preset, LCD display) 4. Test conduction times counter: 0~999999 times (four-station conduction automatic counting, disconnection automatic stop counting) 5. Test speed: 5~60 times/min (knob adjustable, LCD display) 6. Test stroke: 0~60mm (manually adjustable) 7. Conventional clamping range of test fixture: 60×70mm (manually adjustable) 8. Adjustable range of test rod fixture: 0~180mm 9. Overall dimensions (L×W×H): 1000×400×550mm 10. Machine weight: 60kg 11. Working power supply: AC220V, 50HZ

Product Description

Performance benefits

1. The box body is treated with electrostatic painting, and the working table is treated with aluminum sandblasting, which is beautiful and generous, and the whole machine is designed with reasonable structure and fastening, and the operation is stable, safe and accurate. 2. According to the test and manufacture of various key products, the test fixture and stroke are adjustable, and they are widely used. 3. Four groups of stations work at the same time, which greatly improves the test efficiency. 4. Test speed, frequency, humanized design, convenient and fast operation. 5. Each station has a corresponding conduction counter, the key fails, disconnects the conduction, and the corresponding counter will automatically stop counting, so as to facilitate timely knowledge of product-related test information.
