- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
crown
-
Voltage:
-
220/110v
-
Dimension(L*W*H):
-
70*180*60cm
-
Weight:
-
320 kg, 320kg
-
Power:
-
2800W
-
Max cutting width (mm):
-
1490mm
-
Cutting length:
-
0.1mm-999.99m
-
Cutting accuracy (mm):
-
0.1mm
-
Body Material:
-
Anti-Static ABS
-
Cutting speed (p/min):
-
120~150(L=50mm)
-
Knife max temperature (C):
-
cold knife
-
Power supply:
-
AC 220V/50Hz, 110V/60Hz
Quick Details
-
Type:
-
Paper Cutting Machine
-
Production Capacity:
-
150 m/min
-
Max. workable width:
-
1500mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
crown
-
Voltage:
-
220/110v
-
Dimension(L*W*H):
-
70*180*60cm
-
Weight:
-
320 kg, 320kg
-
Power:
-
2800W
-
Max cutting width (mm):
-
1490mm
-
Cutting length:
-
0.1mm-999.99m
-
Cutting accuracy (mm):
-
0.1mm
-
Body Material:
-
Anti-Static ABS
-
Cutting speed (p/min):
-
120~150(L=50mm)
-
Knife max temperature (C):
-
cold knife
-
Power supply:
-
AC 220V/50Hz, 110V/60Hz
Main Features
automotive film, bubble film, pearl cotton, EVA foam cotton, non-woven cloth, polyester cloth, copper foil, aluminum foil and all kinds of sheet, film, paper, ribbon and metal sheet.
printing and packaging industries.
* The machine adopts stepper motor control of fixed length cutting.
* With electric optical tracking system, the machine can process high precision cutting. Cutting accuracy: 0.1mm.
* Cutting materials: packaging foam, insulation paper, kraft paper, PVC film, PET film, automotive film, bubble film, pearl
cotton, EVA foam cotton, non-woven cloth, polyester cloth, copper foil, aluminum foil and all kinds of sheet, film, paper,
ribbon and metal sheet
|
Model
|
WL-1500S
|
|
Cutting width
|
1-1500mm, adjustable
|
|
Cutting length
|
0.1-99999.9mm
|
|
Feeding motor
|
High precision closed-loop motor
|
|
The cutter material
|
SKD-11 high speed steel
|
|
Power
|
220V 50/60Hz
|
|
Cutting speed
|
120-150pcs/min(L=50MM)
|
|
Cutting accuracy
|
0.1mm
|
|
The cutter motor
|
High-power AC motor
|
|
Dimensions
|
700*1800*600mm
|
|
Weight
|
320kg
|
|
Model
|
ZCUT-400S
|
ZCUT-500S
|
ZCUT-600S
|
ZCUT-700S
|
|
Cutting length (mm )
|
1mm-99999mm
|
1mm-99999mm
|
1mm-99999mm
|
1mm-99999mm
|
|
Max cutting width (mm)
|
1-400mm
|
1-500mm
|
1-600mm
|
1-700mm
|
|
Cutting speed(p/min)
|
150
|
150
|
150
|
150
|
|
Knife max temperature (C)
|
cold knife
|
cold knife
|
cold knife
|
cold knife
|
Mainboard
Exclusive use of A-controlled air-conditioning system integration, high memory capacity, large operation rate, high efficiency, high stability and super strength
Knife
Thick knife: Skd-11 high-speed steel can be repeatedly grinded and reused thin knife: Customized imported materials with smooth, sharp incisions and high accuracy
Host
Adopt domestic first-line brand motor, with high strength, high speed, high performance and durability
Drawing-enroller
The highest cutting accuracy of 0.1mm can be achieved by using high quality and high-strength glue for durable wear-resistant cutting.
Operation interface
Chinese and English operation interface
High-definition display
High-definition display, batch, pause, length, compensation , reset key and other functions are clear at a glance
