Quick Details
-
Model Number:
-
C9300L-48PF-4X-E
-
Place of Origin:
-
Beijing, China
-
Product Name:
-
Layer 3 Ethernet network management switch
-
Model:
-
C9300L-48PF-4X-E
-
Fixed Ports:
-
48 port PoE+
-
Uplink Ports:
-
4x 10G/1G fixed uplinks
-
PoE Ports:
-
Supported
-
POE power budget:
-
890W
-
Power Supply:
-
PWR-C1-1100WAC-P
-
Dimensions H x W x D:
-
1.73 x 17.5 x 19.2in
-
Condition:
-
New original sealed packaging
-
Warranty:
-
1 Year
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Brand Name:
-
Other
-
Model Number:
-
C9300L-48PF-4X-E
-
Place of Origin:
-
Beijing, China
-
Product Name:
-
Layer 3 Ethernet network management switch
-
Model:
-
C9300L-48PF-4X-E
-
Fixed Ports:
-
48 port PoE+
-
Uplink Ports:
-
4x 10G/1G fixed uplinks
-
PoE Ports:
-
Supported
-
POE power budget:
-
890W
-
Power Supply:
-
PWR-C1-1100WAC-P
-
Dimensions H x W x D:
-
1.73 x 17.5 x 19.2in
-
Condition:
-
New original sealed packaging
-
Warranty:
-
1 Year
9300 Series Switches Data Sheet
9300 Series switches are lead stackable enterprise access switching platform and as part of the 9000 family, are built to transform your network to handle a hybrid world where the workplace is anywhere, endpoints could be anything, and applications are hosted all over the place.
9300 Series switch configurations
|
Model
|
Total 10/100/1000, Multigigabit copper or SFP Fiber
|
Uplink Configuration
|
Default AC power supply
|
|||
|
Modular uplink models
|
|
|
|
|||
|
C9300X-48HX
|
48 port UPOE+, 48x 10G Multigigabit
|
Modular Uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) with 90W UPOE+
|
|
|
|||
|
C9300X-48TX
|
48 port Data, 48x 10G Multigigabit
|
Modular Uplinks
|
715W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M)
|
|
|
|||
|
C9300X-48HXN
|
48 port UPOE+, 8x 10G Multigigabit
|
Modular Uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) + 40x 5G Multigigabit (5G/2.5G/1G/100M)
|
|
|
|||
|
C9300X-24HX
|
24 port UPOE+, 24x 10G Multigigabit
|
Modular Uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M)
|
|
|
|||
|
C9300X-12Y
|
12 port 25G/10G/1G SFP28
|
Modular Uplinks
|
715W AC
|
|||
|
C9300X-24Y
|
24 port 25G/10G/1G SFP28
|
Modular Uplinks
|
715W AC
|
|||
|
C9300-24T
|
24 port Data
|
Modular Uplinks
|
350W AC
|
|||
|
C9300-48T
|
48 port Data
|
Modular Uplinks
|
350W AC
|
|||
|
C9300-24P
|
24 port PoE+
|
Modular Uplinks
|
715W AC
|
|||
|
C9300-48P
|
48 port PoE+
|
Modular Uplinks
|
715W AC
|
|||
|
C9300-24U
|
24 port UPOE
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-48U
|
48 port UPOE
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-24UX
|
24 port Multigigabit UPOE
|
Modular Uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M)
|
|
|
|||
|
C9300-48UXM
|
48 port UPOE, 36 ports 100M/1G/2.5G + 12聽ports Multigigabit (10G/5G/2.5G/1G/100M)
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-48UN
|
48 port 5Gbps Multigigabit UPOE ports (5G/2.5G/1G/100M)
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-24UB
|
24 port UPOE
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-24UXB
|
24 port Multigigabit UPOE (10G/5G/2.5G/1G/100M)
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-48UB
|
48 port UPOE
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-24H
|
24 port UPOE+
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-48H
|
48 UPOE+
|
Modular Uplinks
|
1100W AC
|
|||
|
C9300-24S
|
24 1G SFP
|
Modular Uplinks
|
715W AC
|
|||
|
C9300-48S
|
48 port 1G SFP
|
Modular Uplinks
|
715W AC
|
|||
|
Fixed uplink models
|
|
|
|
|||
|
C9300L-24T-4G
|
24 port Data
|
4x 1G fixed uplinks
|
350W AC
|
|||
|
C9300L-24T-4X
|
24 port Data
|
4x 10G/1G fixed uplinks
|
350W AC
|
|||
|
C9300L-48T-4G
|
48 port Data
|
4x 1G fixed uplinks
|
350W AC
|
|||
|
C9300L-48T-4X
|
48 port Data
|
4x 10G/1G fixed uplinks
|
350W AC
|
|||
|
C9300L-24P-4G
|
24 port PoE+
|
4x 1G fixed uplinks
|
715W AC
|
|||
|
C9300L-24P-4X
|
24 port PoE+
|
4x 10G/1G fixed uplinks
|
715W AC
|
|||
|
C9300L-48P-4G
|
48 port PoE+
|
4x 1G fixed uplinks
|
715W AC
|
|||
|
C9300L-48P-4X
|
48 port PoE+
|
4x 10G/1G fixed uplinks
|
715W AC
|
|||
|
C9300L-48PF-4G
|
48 port PoE+
|
4x 1G fixed uplinks
|
1100W AC
|
|||
|
C9300L-48PF-4X
|
48 port PoE+
|
4x 10G/1G fixed uplinks
|
1100W AC
|
|||
|
C9300L-24UXG-4X
|
24 port UPOE, 8 ports Multigigabit
|
4x 10G/1G fixed uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) + 16 ports 1G聽(1G/100M/10M)
|
|
|
|||
|
C9300L-24UXG-2Q
|
24 port UPOE, 8 ports Multigigabit
|
2x 40G fixed uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) + 16 ports 1G聽(1G/100M/10M)
|
|
|
|||
|
C9300L-48UXG-4X
|
48 port UPOE, 12 ports Multigigabit
|
4x 10G/1G fixed uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) + 36 port 1G (1G/100M/10)
|
|
|
|||
|
C9300L-48UXG-2Q
|
48 port UPOE, 12 port Multigigabit
|
2x 40G fixed uplinks
|
1100W AC
|
|||
|
|
(10G/5G/2.5G/1G/100M) + 36 port 1G聽(1G/100M/10M)
|
|
|
|||
|
C9300LM-48UX-4Y
|
48 port UPOE, 8 port 10G Multigigabit (10G/5G/2.5G/1G/100M) + 40 port 1G (1G/100M/10M)
|
4x25G fixed uplinks
|
1000W AC
|
|||
|
C9300LM-48U-4Y
|
48 port 1G (1G/100M/10M) with UPOE
|
4x25G fixed uplinks
|
1000W AC
|
|||
|
C9300LM-24U-4Y
|
24 port 1G (1G/100M/10M) with UPOE
|
4x25G fixed uplinks
|
600W AC
|
|||
|
C9300LM-48T-4Y
|
48 port 1G (1G/100M/10M) Data
|
4x25G fixed uplinks
|
600W AC
|
|||
Related products
Hubei Netstar Yiyue Technology Co., Ltd
Do you have any questions about these products?
Contact us
Chat now
or zhuang
@hkbarrette.com
Network module numbers and descriptions
|
Network module
|
Network module
|
|
C9300X-NM-8M
|
9300X 8x 10G/1G Multigigabit Network Module
|
|
C9300X-NM-8Y
|
9300X 8x 25G/10G/1G Network Module
|
|
C9300X-NM-2C
|
9300X 2x 100G/40G Network Module
|
|
C9300X-NM-4C*
|
9300X 4x 100G/40G Network Module
|
|
C9300-NM-4G
|
9300 Series 4x 1G Network Module
|
|
C9300-NM-4M
|
9300 Series 4x Multigigabit Network Module
|
|
C9300-NM-8X
|
9300 Series 8x 10G/1G Network Module
|
|
C9300-NM-2Q
|
9300 Series 2x 40G Network Module
|
|
C9300-NM-2Y
|
9300 Series 2x 25G/10G/1G Network Module
|
|
Power supply models
|
|
|
|
|
|
|
|
|||
|
Models
|
Primary Power Supply
|
Default or Upgrade
|
Available PoE
|
With 350W Secondary PS
|
With 715W secondary PS
|
With 1100W Secondary PS
|
With 1900W Secondary PS
|
|||
|
C9300X-48HX
|
PWR-C1-1900WAC-P
|
Upgrade
|
1390W
|
1740W
|
2105W
|
2490W
|
3290W
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
590W
|
940W
|
1305W
|
1690W
|
2490W
|
|||
|
C9300X-48TX
|
PWR-C1-715WAC-P
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9300X-48HXN
|
PWR-C1-1900WAC-P
|
Upgrade
|
1490W
|
1840W
|
2205W
|
2590W
|
3390W
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
690W
|
1040W
|
1405W
|
1790W
|
2590W
|
|||
|
C9300X-24HX
|
PWR-C1-1900WAC-P
|
Upgrade
|
1535W
|
1885W
|
2160W*
|
2160W*
|
2160W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
735W
|
1085W
|
1450W
|
1835W
|
2160W*
|
|||
|
C9300X-24Y
|
PWR-C1-715WAC-P
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9300X-12Y
|
PWR-C1-715WAC-P
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9300-48H
|
PWR-C1-1900WAC-P
|
Upgrade
|
1622W
|
1972W
|
2337W
|
2722W
|
2880W
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
822W
|
1172W
|
1537W
|
1922W
|
2722W
|
|||
|
C9300-24H
|
PWR-C1-1900WAC-P
|
Upgrade
|
1630W
|
1980W
|
2160W*
|
2160W*
|
2160W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
830W
|
1180W
|
1545W
|
1930W
|
2160W
|
|||
|
C9300-48UN
|
PWR-C1-1900WAC-P
|
Upgrade
|
1445W
|
1795W
|
2160W
|
2545W
|
2880W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
645W
|
995W
|
1360W
|
1745W
|
2545W
|
|||
|
C9300-48UXM
|
PWR-C1-1900WAC-P
|
Upgrade
|
1290W
|
1640W
|
2005W
|
2880W*
|
2880W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
490W
|
840W
|
1205W
|
1590W
|
2390W
|
|||
|
C9300-24UX
|
PWR-C1-1900WAC-P
|
Upgrade
|
1360W
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
560W
|
910W
|
1275W
|
1440W*
|
1440W*
|
|||
|
C9300-48U
|
PWR-C1-1900WAC-P
|
Upgrade
|
1622W
|
1800W**
|
1800W**
|
1800W**
|
1800W**
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
822W
|
1172W
|
1537W
|
1800W**
|
1800W**
|
|||
|
C9300-24U
|
PWR-C1-1900WAC-P
|
Upgrade
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
830W
|
1180W
|
1152W
|
1440W*
|
1440W*
|
|||
|
C9300-48P
|
PWR-C1-1100WAC-P
|
Upgrade
|
822W
|
1172W
|
1440W*
|
1440W*
|
1440W*
|
|||
|
|
PWR-C1-715WAC-P
|
Default
|
437W
|
787W
|
1152W
|
1440W*
|
1440W*
|
|||
|
C9300-24P
|
PWR-C1-1100WAC-P
|
Upgrade
|
720W*
|
720W*
|
720W*
|
720W*
|
720W*
|
|||
|
|
PWR-C1-715WAC-P
|
Default
|
445W
|
720W*
|
720W*
|
720W*
|
720W*
|
|||
|
C9300-48T
|
PWR-C1-350WAC-P***
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9300-24T
|
PWR-C1-350WAC-P***
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9200-48S
|
PWR-C1-715WAC-P
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9200-24S
|
PWR-C1-715WAC-P
|
Default
|
No POE
|
No POE
|
No POE
|
No POE
|
No POE
|
|||
|
C9300-48UB
|
PWR-C1-1900WAC-P
|
Upgrade
|
1622W
|
1800W**
|
1800W**
|
1800W**
|
1800W**
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
822W
|
1172W
|
1537W
|
1800W**
|
1800W**
|
|||
|
C9300-24UB
|
PWR-C1-1900WAC-P
|
Upgrade
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
830W
|
1180W
|
1440W*
|
1440W*
|
1440W*
|
|||
|
C9300-24UXB
|
PWR-C1-1900WAC-P
|
Upgrade
|
1360W
|
1440W*
|
1440W*
|
1440W*
|
1440W*
|
|||
|
|
PWR-C1-1100WAC-P
|
Default
|
560W
|
910W
|
1275W
|
1440W*
|
1440W*
|
|||
|
C9300L-24T-4G
|
PWR-C1-350WAC-P
|
Default
|
No PoE
|
No PoE
|
No PoE
|
No PoE
|
-
|
|||
|
C9300L-24T-4X
|
PWR-C1-350WAC-P
|
Default
|
No PoE
|
No PoE
|
No PoE
|
No PoE
|
-
|
|||
|
C9300L-48T-4G
|
PWR-C1-350WAC-P
|
Default
|
No PoE
|
No PoE
|
No PoE
|
No PoE
|
-
|
|||
|
C9300L-48T-4X
|
PWR-C1-350WAC-P
|
Default
|
No PoE
|
No PoE
|
No PoE
|
No PoE
|
-
|
|||
|
C9300L-24P-4G
|
PWR-C1-715WAC-P
|
Default
|
505W
|
720W*
|
720W*
|
720W*
|
-
|
|||
|
C9300L-24P-4X
|
PWR-C1-715WAC-P
|
Default
|
505W
|
720W*
|
720W*
|
720W*
|
-
|
|||
|
C9300L-48P-4G
|
PWR-C1-715WAC-P
|
Default
|
505W
|
855W
|
1220W
|
1440W*
|
-
|
|||
|
C9300L-48P-4X
|
PWR-C1-715WAC-P
|
Default
|
505W
|
855W
|
1220W
|
1440W*
|
-
|
|||
|
C9300L-48PF-4G
|
PWR-C1-1100WAC-P
|
Default
|
890W
|
1240W
|
1440W
|
1440W*
|
-
|
|||
|
C9300L-48PF-4X
|
PWR-C1-1100WAC-P
|
Default
|
890W
|
1240W
|
1440W
|
1440W*
|
-
|
|||
|
C9300L-24UXG-4X
|
PWR-C1-1100WAC-P
|
Default
|
880W
|
1230W
|
1440W
|
1440W*
|
-
|
|||
|
C9300L-24UXG-2Q
|
PWR-C1-1100WAC-P
|
Default
|
722W
|
1072W
|
1440W
|
1440W*
|
-
|
|||
|
C9300L-48UXG-4X
|
PWR-C1-1100WAC-P
|
Default
|
675W
|
1025W
|
1390W
|
1775W
|
-
|
|||
|
C9300L-48UXG-2Q
|
PWR-C1-1100WAC-P
|
Default
|
675W
|
1025W
|
1390W
|
1775W
|
-
|
|||
|
C9300LM-48UX-4Y
|
PWR-C6-1KWAC
|
Default
|
790W
|
1390W
|
1505W
|
1790W
|
-
|
|||
|
C9300LM-48U-4Y
|
PWR-C6-1KWAC
|
Default
|
790W
|
1390W
|
1505W
|
1790W*
|
-
|
|||
|
C9300LM-24U-4Y
|
PWR-C6-1KWAC
|
Upgrade
|
820W
|
1420W
|
1440W*
|
1440W*
|
-
|
|||
|
|
PWR-C6-600WAC
|
Default
|
420W
|
1020W
|
1135W
|
1420W
|
-
|
|||
|
C9300LM-48T-4Y
|
PWR-C6-600WAC
|
Default
|
No PoE
|
No PoE
|
No PoE
|
No PoE
|
-
|
|||
