Quick Details
-
Brand Name:
-
Depower
-
Model Number:
-
PCC08 G4
-
Work Time (h):
-
24
-
Certificate:
-
CE
-
Warranty:
-
24M, 3 Years
-
Rated Voltage:
-
12v
-
Certification:
-
CE RoHS ISO9001
-
Level of protection:
-
IP68
-
Max Charge Current:
-
8A
-
Battery voltage:
-
12V
-
Max. LED drive power:
-
40W
-
Max. LED drive voltage:
-
16~50V
-
Control Mode:
-
3 Stage PWM Charge Mode
-
Function:
-
light and time control
Quick Details
-
Type:
-
PWM
-
Application:
-
Charger Controller, Solar System Controller
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Depower
-
Model Number:
-
PCC08 G4
-
Work Time (h):
-
24
-
Certificate:
-
CE
-
Warranty:
-
24M, 3 Years
-
Rated Voltage:
-
12v
-
Certification:
-
CE RoHS ISO9001
-
Level of protection:
-
IP68
-
Max Charge Current:
-
8A
-
Battery voltage:
-
12V
-
Max. LED drive power:
-
40W
-
Max. LED drive voltage:
-
16~50V
-
Control Mode:
-
3 Stage PWM Charge Mode
-
Function:
-
light and time control
Professional design to promote system reliability
Using international well-know brand semiconductor device such as IR, ST, ON and so on.
High LED driving, significantly reduce the product temperature.
IP68 protection degree without any buttons, further improve the waterproof reliability.
Discharge efficiency
LED constant current drive efficiency up to 96%
Dimming LED constant current drive efficiency from 91%-96%
Minimal power consumption
The current consumption ≤10mA
Intelligent battery management
It is PWM and CV charge, which matches with Li protect board perfectly.
Significantly extends the battery lifetime up to 50% base on intelligent temperature compensation charge and discharge management.
Intelligent energy management of battery ensures that the battery charge & discharge in shallow state which significantly extend the battery life.
Intelligent LED drive management
Light control function, automatic lights LED in the dark, turn off automatically at dawn
Constant current drive
Five time control.
Infrared body sensor
Delaying infrared body sensor
Dimming function, control to output different power in different typical time.
Flexible parameter set
Excellent man-machine interface, convenient operation.
Infrared wireless communications, connecting with a handheld remote control for easy installation.
Protect function
Battery reverse connection protection.
The solar panel reverse connection protection.
To prevent the battery discharge to the solar panel .
Battery low voltage disconnect protection.
Battery reconnect voltage protection.
The LED output short and open circuit protection.
