Quick Details
-
Light Source:
-
LED
-
Color Rendering Index(Ra):
-
100
-
Working Time (hours):
-
100000
-
Input Voltage(V):
-
85~265VAC 50/60Hz
-
Lamp Luminous Flux(lm):
-
90
-
CRI (Ra):
-
100
-
Beam Angle(°):
-
360° in Horizontal Direction.
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
SIEN
-
Products name:
-
LED Medium Intensity Obstruction Light
-
International standard:
-
ICAO(Aerodromes Annex 14)Medium Intensity Light
-
Standard:
-
FAA Advisory Circular AC150/5370-2F L864
-
Intensity:
-
2000cd
-
Visual Range:
-
>10km
-
Working mode:
-
Steady Burning/Flashing
-
Application:
-
Telecom Tower, Stack, Chimney ,Tower Crane, Building
Quick Details
-
Warranty(Year):
-
2-Year
-
Color Temperature(CCT):
-
red
-
Lamp Body Material:
-
Aluminum Alloy
-
Light Source:
-
LED
-
Color Rendering Index(Ra):
-
100
-
Working Time (hours):
-
100000
-
Input Voltage(V):
-
85~265VAC 50/60Hz
-
Lamp Luminous Flux(lm):
-
90
-
CRI (Ra):
-
100
-
Beam Angle(°):
-
360° in Horizontal Direction.
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
SIEN
-
Products name:
-
LED Medium Intensity Obstruction Light
-
International standard:
-
ICAO(Aerodromes Annex 14)Medium Intensity Light
-
Standard:
-
FAA Advisory Circular AC150/5370-2F L864
-
Intensity:
-
2000cd
-
Visual Range:
-
>10km
-
Working mode:
-
Steady Burning/Flashing
-
Application:
-
Telecom Tower, Stack, Chimney ,Tower Crane, Building
Introduction
Aircraft warning lights
are high-intensity lighting devices that are attached to tall structures and are used as collision avoidance measures. Such devices make structures more visible to passing aircraft and are usually used at night, although they may be used during the day as well. These lights need to be of sufficient brightness in order to be visible for miles around the structure.
The light we produce is maintenance-free, complying with
ICAO and FAA international standards
.This light can be used for marking obstacles which pose a threat to aircraft, such as telecom towers, buildings, wind turbines, power transmission towers, airports and general aviation warning purposes.
Specification
|
Main Specification
|
|
|
|
Product
|
Single Medium Intensity Light
|
|
|
Intensity
|
2000cd
|
|
|
Visible Range
|
>10Km
|
|
|
Light Source
|
Cree High Power LED
|
|
|
Light Color
|
Aviation Red
|
|
|
Power
|
30W
|
|
|
Waterproof
|
IP66
|
|
|
Operating Voltage
|
110~240VAC
|
|
|
Warranty
|
5 years
|
|
Products Description
|
Product Details
This light fixture is a dedicated maintenance-free obstacle light for aviation warning purposes. It is complying with ICAO and FAA international standards. This light can be used for marking obstacles which pose a threat to aircraft, such as telecom towers, buildings,wind turbines ,power transmission towers, airports and general aviation waring purposes.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Its advanced high-power LED with optimized optical design is able to minimal power consumption and maximize light intensity based on only one single LED. Energy saving compare to incandescent lighting technology. Meanwhile increasing safety thanks to low failure LED technology. Our LED obstruction light offer an ultra bright,energy efficiency, reliability and freedom from maintenance mean that our light will save you money over time!
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Features
➢
Cree LED, 100,000 hours lifetime. High light efficiency and energy saving.
➢
A large arc reflector can limit light beam within effective range, reducing light pollution and improving light efficiency.
➢
Using LED constant current drive technology and aluminum cooling technology so as to maximize LED life.
➢
Lighthouse is made of PC material. It is able to anti-UV, good at impact strength, thermal stability and flame retardancy.
➢
High reliability seal design to meet IP66.
➢
It is with integrated junction box, which is convenient for customer wiring connection.
➢
Reverse polarity protected (DC Type).
➢
Option function: light sensor (photocell) for day/light operation
Optional steady burning or flashing.
Optional faulty alarm output
Optional GPS Synchronization
|
Specification
|
|
|
Light model
|
MIL2KS
|
|
Light source
|
Cree LED
|
|
Intensity
|
>2000cd±25%cd
|
|
Visible Range
|
>10km
|
|
Horizontal Output(degree)
|
360
|
|
Vertical Output(degree)
|
10
|
|
LED color
|
Red as standard.Other colors available on request.
|
|
Electrical characteristics
|
|
|
Operating voltage
|
110~240VAC, 48VDC, 24VDC
|
|
Power consumption
|
30~48W
|
|
Driven mode
|
Constant current
|
|
Mechanical characteristics
|
|
|
Body Material
|
Die casting aluminum
|
|
Housing Material
|
PC UV Stabilize
|
|
Weight
|
7.00KG
|
|
Dimension
|
See diagram
|
|
Mounting
|
Flat Installation
|
|
Working temperature
|
-40˚C~+70˚C
|
|
Humidity
|
10% ~95%
|
|
Wind speed
|
Up to 150mph(240kph)
|
|
Waterproof
|
IP66
|
Product Applications
Certificate
Our Service
We provide 5 years warranties for our products.
Check below important tips before you placing an order :
1.Inquiry-Professional quotation. Please tell us your application for the product(Applying for tower/windturbine/crane/building/chimney/etc). Our sales will offer you with professional quotation basing on your application.
2. Confirm the price, lead time, artwork, payment term etc.
3.our sales send the Proforma Invoice with our seal.
4. Customer make the payment for deposit and send us Bank receipt.
5. Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party Inspection .
6. Clients make payment for balance and Ship the goods , Inform the tracking number and check the status for clients.
7. Order can be say "finish" when you receive the goods and satisfy with them .
8. Feedback to our about Quality , Service, Market Feedback & Suggestion. And we can do better .
