- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
ASIA
-
Model Number:
-
Steel Structure Warehouse Workshop
-
Product name:
-
Light Steel Structure House Carport Steel Frame Prefab House
-
Keyword:
-
Steel Metal Frame Structure
-
Application Fields:
-
House,Warehouse, Workshop,
-
Material:
-
Q235/Q235B/Q345/Q345B
-
Purlin:
-
C.Z Shape Galvanized Steel Channel
-
Surface treatment:
-
Hot dipped galvanized
-
Main frame:
-
Solid H-shape Steel Beam
-
Beam:
-
H-section Beam
-
Certificate:
-
CE Certification
Quick Details
-
Grade:
-
Q235 Q235B Q345Q345B Q355B
-
Tolerance:
-
±1%
-
Place of Origin:
-
TIANJIN, CHINA
-
Brand Name:
-
ASIA
-
Model Number:
-
Steel Structure Warehouse Workshop
-
Product name:
-
Light Steel Structure House Carport Steel Frame Prefab House
-
Keyword:
-
Steel Metal Frame Structure
-
Application Fields:
-
House,Warehouse, Workshop,
-
Material:
-
Q235/Q235B/Q345/Q345B
-
Purlin:
-
C.Z Shape Galvanized Steel Channel
-
Surface treatment:
-
Hot dipped galvanized
-
Main frame:
-
Solid H-shape Steel Beam
-
Beam:
-
H-section Beam
-
Certificate:
-
CE Certification
Products Description
STEEL STURCTURE
Steel structure building ware-house/workshop is a new type of light steel structure building system formed from a main steel framework comprised of H section, Z section and U section steel components, the roof and walls utilizing a variety of panels andother components such as windows, doors, and cranes.
|
Item
|
|
Specifications
|
|
|
|||
|
Main Steel Frame
|
Column
|
Q235, Q235B, , Q345BWelded H Section Steel
|
|
|
|||
|
|
Beam
|
Q235, Q235B, Q345, Q345BWelded H Section Steel
|
|
|
|||
|
Secondary Frame
|
Purlin
|
Q235 C and Z purlin
|
|
|
|||
|
|
Knee brace
|
Q235 Q345 Angle Steel
|
|
|
|||
|
|
Tie Rod
|
Q235 Q345 Circular Steel Pipe
|
|
|
|||
|
|
Brace
|
Q235 Q345 Round Bar
|
|
|
|||
|
|
Vertical and Horizontal Support
|
Q235 Q345 Angle Steel, Round Bar or Steel Pipe
|
|
|
|||
|
Maintenance system
|
Wall and roof
|
Corrugated Steel Sheet/EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
|
|
|
|||
|
Accessories
|
Window
|
1.Sliding window
2.Plastic-steel frame or aluminum frame 3.According to your requirementsWindow |
|
|
|||
|
|
Door
|
1.Roller door
2.Sliding door and sidewall door 3.Steel sheet, sandwich panel or aluminum-alloy. 4.According to your requirements |
|
|
|||
|
|
Gutter
|
1.Aluminum-zinc steel sheet
2.Stainless sheet |
|
|
|||
|
|
Rainspout
|
PVC
|
|
|
|||
|
Surface Treatment
|
|
Hot dipped galvanized or Painted
|
|
|
|||
|
Wind Resistance Grade
|
|
12 Grades
|
|
|
|||
|
Earthquake-resistance
|
|
8 Grades
|
|
|
|||
|
Structure Usage
|
|
Up to 50 years
|
|
|
|||
Hot Sale Painted Galvanized Light Steel Structure House Carport Steel Frame Prefab House
Advantages of our products:
1) Cost saving and transportation convenient, custom design available steel building
2) The main beam and column are made of quality steel material Q355B Q345B Q235B steel structure workshop
3) Steel structure makes the house resist heavy wind of 180km/h and 9-grade earthquake steel structures
4) Easy assembly and disassembly several times without damage steel structure shed
5) Widely used in construction site, office building, dormitory etc. steel structures
6) Good environmental protection effect. Steel structure housing construction greatly reduces sand, stone and dosage of the
ash.Most of the used materials are recyclable or degradable, little rubbish produced steel frame structure.
2) The main beam and column are made of quality steel material Q355B Q345B Q235B steel structure workshop
3) Steel structure makes the house resist heavy wind of 180km/h and 9-grade earthquake steel structures
4) Easy assembly and disassembly several times without damage steel structure shed
5) Widely used in construction site, office building, dormitory etc. steel structures
6) Good environmental protection effect. Steel structure housing construction greatly reduces sand, stone and dosage of the
ash.Most of the used materials are recyclable or degradable, little rubbish produced steel frame structure.
Application
