- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Workshop
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Anlin
-
Model Number:
-
600
-
Product Name:
-
garage door
-
Rated Voltage:
-
220V /110V
-
Output Torque (N.m):
-
168
-
Rated Frequency:
-
50Hz
-
Rated Power (W):
-
250
-
Rated Current (A):
-
1.9
-
Lifting Force (kg.f):
-
300
-
Max Lifting Height (m):
-
6
-
Rated Output Speed(r/min):
-
5.4
-
Continued Working Time(min):
-
7
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Workshop
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Anlin
-
Model Number:
-
600
-
Product Name:
-
garage door
-
Rated Voltage:
-
220V /110V
-
Output Torque (N.m):
-
168
-
Rated Frequency:
-
50Hz
-
Rated Power (W):
-
250
-
Rated Current (A):
-
1.9
-
Lifting Force (kg.f):
-
300
-
Max Lifting Height (m):
-
6
-
Rated Output Speed(r/min):
-
5.4
-
Continued Working Time(min):
-
7
Anlin changes the traditional shutter door motor and leads the whole industry. We invite you to join the "blue ocean plan" for win-win development.
| Technical Specifications | |||||||||
| Model |
Rated Voltage |
Rated Frequency |
Rated Power (W) |
Rated Current (A) |
Lifting Force (kg.f) |
Output Torque (N.m) |
Rated Output Speed (r/min) |
Max Lifting Height (m) |
Continued Working Time (min) |
| QL-200-1P(200kg) | 220V/110V | 50Hz | 180 | 2.8 | 200 | 84 | 5 | 4 | 7 |
| QL-300-1P(300kg) | 220V /110V | 50Hz | 250 | 1.9 | 300 | 168 | 5.4 | 6 | 7 |
| QL-400-1P(400kg) | 220V /110V | 50Hz | 300 | 3.2 | 400 | 225 | 5.4 | 6 | 7 |
| QL-500-1P(500kg) | 220V /110V | 50Hz | 370 | 3.3 | 500 | 343 | 5.7 | 6 | 7 |
| QL-600-1P(600kg) | 220V /110V | 50Hz | 370 | 3.3 | 600 | 412 | 5.3 | 6 | 7 |
| QL-700-1P(700kg) | 220V/110V | 50Hz | 370 | 3.9 | 700 | 509 | 5.3 | 6 | 7 |
| QL-800-1P(800kg) | 220V /110V | 50Hz | 400 | 4.5 | 800 | 647 | 4.6 | 9 | 7 |
The Mechanics limit USP lightning protection circuit Advanced friction material limit precisely , operational safety Low failure rate , long service life.
