Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for
producing PET plastic containers and bottles in all shapes.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SCY
-
Voltage:
-
13PH-50/60H2-208-230V.380-420V.440-480V
-
Dimension(L*W*H):
-
1300*780*1530 mm
-
Weight:
-
400 KG
-
Power:
-
4.8KW
-
Working Temperature Range:
-
5-35
-
Refrigerant Type:
-
R134a, R407c, R410a
-
Power consumption:
-
9.35kw
-
Running current:
-
18.1A
-
Freeze water flow:
-
4.8m3/h
-
Compressor Type:
-
Scroll
-
Compressor Input power:
-
7.5kw
-
Pump power:
-
0.75kw
-
Evaporator Type:
-
Shell and Tube, Plate, Copper Tube
-
Fan Power:
-
1.1kw
Quick Details
-
Core Components:
-
Compressor, Condenser, Evaporator, Expansion valve
-
Condition:
-
Brand New
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SCY
-
Voltage:
-
13PH-50/60H2-208-230V.380-420V.440-480V
-
Dimension(L*W*H):
-
1300*780*1530 mm
-
Weight:
-
400 KG
-
Power:
-
4.8KW
-
Working Temperature Range:
-
5-35
-
Refrigerant Type:
-
R134a, R407c, R410a
-
Power consumption:
-
9.35kw
-
Running current:
-
18.1A
-
Freeze water flow:
-
4.8m3/h
-
Compressor Type:
-
Scroll
-
Compressor Input power:
-
7.5kw
-
Pump power:
-
0.75kw
-
Evaporator Type:
-
Shell and Tube, Plate, Copper Tube
-
Fan Power:
-
1.1kw
Details Images
Title goes here.
Why Choose Us
Product Paramenters
|
Model
|
|
SCY-10A
|
||
|
Power supply
|
|
208-230V, 380-420V,440-480V,50Hz or 60Hz, 3phase
|
||
|
Cooling capacity
|
kw
|
28.5
|
||
|
|
TONS
|
8.10
|
||
|
|
Kcal/h
|
24510
|
||
|
Power consumption
|
kw
|
9.35
|
||
|
Running current
|
A
|
18.1
|
||
|
Freeze water flow
|
m³/h
|
4.8
|
||
|
Compressor
|
Type
|
Scroll
|
||
|
|
Input power(kw)
|
7.5
|
||
|
Pump
|
Power(kw)
|
0.75
|
||
|
Refrigerant
|
Type
|
R22, R134a, R407c, R410a
|
||
|
|
Control method
|
External balanced thermostatic expansion valve
|
||
|
|
Filling volume(kg)
|
6
|
||
|
Evaporator
|
Type
|
Shell and tube, Plate, Coil in Tank
|
||
|
|
Pipe diameter(in)
|
1-1/2"
|
||
|
Condenser
|
Type
|
High efficient Finned Copper Tube
|
||
|
Fan
|
Type
|
Axial-flow Fan
|
||
|
|
Air volume(m³/h)
|
10000
|
||
|
|
Power(kw)
|
1.1
|
||
|
Safty protector
|
|
Dual pressure switch, frost-proof protection, soluble pin/safety valve, overload protective device, coil over-heating protection
system, temperature automatic protection switch. |
||
|
Dimension
|
Length(mm)
|
1300
|
||
|
|
Width(mm)
|
780
|
||
|
|
Height(mm)
|
1530
|
||
|
Weight(kg)
|
|
400
|
||
|
1. Testing results under above conditions: Inlet/outlet chilled water temperature 12℃/7℃, condensing temperature 45℃.
|
|
|
||
|
2. The above parameters will be updated continuously. If you need a custom service, please send your technical requirements before
placing an order. |
|
|
||
