Quick Details
-
Model Number:
-
KCD1-101-3pins
-
Max. Current:
-
10(4)A
-
Mechanical Life:
-
10,000 Cycles
-
Products Name:
-
Rocker Switch
-
Rated Voltage/Rated Current:
-
3A 250VAC/6A 125VAC
-
Certificate:
-
CE FCC ROHS
-
Color:
-
Black
-
Insulation Resistance:
-
≥100MΩ
-
Material:
-
Brass
-
Shape:
-
Square
-
Size:
-
15*21mm
-
Contact Resistance:
-
≤50mΩ
-
Operating Temperature:
-
-25℃+85℃(T85)
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SZGOZIE
-
Model Number:
-
KCD1-101-3pins
-
Max. Current:
-
10(4)A
-
Mechanical Life:
-
10,000 Cycles
-
Products Name:
-
Rocker Switch
-
Rated Voltage/Rated Current:
-
3A 250VAC/6A 125VAC
-
Certificate:
-
CE FCC ROHS
-
Color:
-
Black
-
Insulation Resistance:
-
≥100MΩ
-
Material:
-
Brass
-
Shape:
-
Square
-
Size:
-
15*21mm
-
Contact Resistance:
-
≤50mΩ
-
Operating Temperature:
-
-25℃+85℃(T85)
-
Certification:
-
CE
Specification
|
Product Name
|
Conjoined Rocker Switch
|
Rated Current/Rated Voltage
|
5A
|
|
Item Number
|
Rocker switch KCD1-101
|
Contact Resistance
|
<50MΩ
|
|
Funtion
|
ON-OFF
|
Insulation Resistance
|
>1000MΩ
|
|
Electronic Life
|
>10,000 Cycles
|
Withstand Voltage
|
>1500V/MINUTE
|
|
Mechanical Life
|
>10,000 Cycles
|
Ambient Temperature
|
-10°C~+85°C
|
|
Dielectric Strength
|
≥1500VAC/min
|
Storage Temperature
|
-25°C~+85°C
|
Product Description
Temperature test
Other types of different square rocker switch
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
