Quick Details
-
Model Number:
-
KCD1-8013A
-
Max. Current:
-
30A
-
Mechanical Life:
-
50000 Cycles
-
Product name:
-
rocker switch
-
Rating:
-
20A 125VAC; 16A 250VAC
-
Lamp color:
-
Red/Blue/Green/Yellow/White
-
Function:
-
ON-OFF,ON-OFF-ON
-
Application:
-
Electric Equipment
-
Working Temperature:
-
-25℃~+125℃
-
Material:
-
PA66/PC
-
Pins:
-
2P\3P\4P\6P
-
Warranty:
-
2 Years
-
Product Type:
-
Waterproof Rocker Switch
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
KCD1-8013A
-
Max. Current:
-
30A
-
Mechanical Life:
-
50000 Cycles
-
Product name:
-
rocker switch
-
Rating:
-
20A 125VAC; 16A 250VAC
-
Lamp color:
-
Red/Blue/Green/Yellow/White
-
Function:
-
ON-OFF,ON-OFF-ON
-
Application:
-
Electric Equipment
-
Working Temperature:
-
-25℃~+125℃
-
Material:
-
PA66/PC
-
Pins:
-
2P\3P\4P\6P
-
Warranty:
-
2 Years
-
Product Type:
-
Waterproof Rocker Switch
-
Certification:
-
CE
Products Description
250VAC 16A Colorful 6pin Rocker Switch Double Pole Rocker Switch 21x15mm Black Waterproof Mini On Off 2 Position 2 Pin 6A 250VAC
Features:
1. Mounting size from 13.8mm to 35mm long
2. Common Actuator Color: red, green,black
3.Momentary or Latching(self-locking) function available
4.Widely applied to control all kinds of household appliances such as water dispenser, treadmill, coffee potand so on.
How to choose Rocker switch function?
1. OFF-(ON): Push to ON (momentary) function,When you push switch,it will be power ON, and then release your finger, the actuator
will back to the original position.
2. ON-(OFF): Push to OFF (momentary) function,When you push switch,it will be power OFF, and then release your finger, the
actuator will back to the original position.
3. ON-OFF: Latching (Self-locking) function,When you press the button, it will be ON and keeps locked until you press again, it will return to original position.
Note:
1. OFF-(ON): Push to ON (momentary) function,When you push switch,it will be power ON, and then release your finger, the actuator
will back to the original position.
2. ON-(OFF): Push to OFF (momentary) function,When you push switch,it will be power OFF, and then release your finger, the
actuator will back to the original position.
3. ON-OFF: Latching (Self-locking) function,When you press the button, it will be ON and keeps locked until you press again, it will return to original position.
Note:
-Our Rocker switch has different functions, please check our function description on each item before order,thanks!
-size and it slides straight in.This inexpensive rocker switches are always good to have around.
· Widely used for various kinds of electrical products, instrument, car, boat, household appliances such as lights, water dispenser, treadmill, coffee pot, speaker, electric car, motorcycle, TV, massage machine etc
-size and it slides straight in.This inexpensive rocker switches are always good to have around.
· Widely used for various kinds of electrical products, instrument, car, boat, household appliances such as lights, water dispenser, treadmill, coffee pot, speaker, electric car, motorcycle, TV, massage machine etc
|
Product Name
|
Rocker Switch
|
|
Enclosure Material
|
Plastic
|
|
Application
|
For Machine,Boat,Electronic appliances
|
|
Contact Resistance
|
35mΩ max
|
|
Insulation Resistance
|
500VDC 100mΩ Min
|
|
Dielectric Intensity
|
1500VAC,1 minute
|
|
Operating Temperature
|
-25°C ~+85°C
|
|
Electrical Life
|
10000 Cycles
|
|
Packing
|
100pcs/Bag
|
|
Order Confirm
|
What’s actuator color?
|
|
What You Get
|
1X Rocker switch
|
