customize portable ready to living 2 bedroom 4 bedroom tiny hotel resort pool shipping house building container houses

No

Name

Model

1

Top Frame

2 branch long beam
2 branch short beam
Top corner piece 4 piece

2 branch top secondary beam C-shaped steel
2 branch galvanized square tube

2

Bottom Frame

2 branch long beam
2 branch short beam
bottom corner piece 4 piece.

bottom secondary beam:galvanized square tube

18mm Cement sanding board.

3

Column

Galvanized column,4 pieces.

4

Auxiliary Materials

diameter 50mm PVC downpipe(thickened type）

column package（05）

50 floodwater tank

Self tapping screws, rivets, hexagonal socket bolts, adhesives, etc

5

Electrical Distribution

Industrial socket box+industrial socket 32A、Distribution box（1 not covered）2 ordinary socket、1air conditioning socket，2 set LED
strip lamp，principal line 3*6m²,three hole socket cable（for air conditioning）3*4m²。Five hole socket cable 3*2.5m².switched line
2*1.5m²。

6

Door

Special door for Container House，0.35mm

7

Window

Special plastic steel sliding window for Container House ，single glass single push with screen window,security window.

8

Wall Board

950 type 50mm rock wool composite board，double sided iron sheet0.2mm，unit weight 50kg，double orange peel pattern,single sided
lamination.
