Quick Details
-
Customized support:
-
oem
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SMATRUL
-
Model Number:
-
WHC01-B-TH(2GANG)2RE
-
Item Type:
-
TOUCH Switches
-
Certification:
-
ce, RoHS, FCC
-
Switch Type:
-
Remote Control
-
Remote Distance:
-
Up to 50m (theoretical distance)
-
Controller Operating Voltage:
-
AC 85V-240V 110V 220V 60HZ/50HZ
-
Controller working frequency:
-
433.92MHZ
-
Controller Maximum power:
-
<1000W
-
Controller Receiving sensitivity:
-
-108dBM
-
wireless switch battery:
-
CR2032 Alkaline Battery ( Not Included Battery)
-
wireless switch Coding method:
-
Learning Code EV 1527
Quick Details
-
Max. Current:
-
10A
-
Max. Voltage:
-
110v-220v
-
Network:
-
OTHER
-
Customized support:
-
oem
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SMATRUL
-
Model Number:
-
WHC01-B-TH(2GANG)2RE
-
Item Type:
-
TOUCH Switches
-
Certification:
-
ce, RoHS, FCC
-
Switch Type:
-
Remote Control
-
Remote Distance:
-
Up to 50m (theoretical distance)
-
Controller Operating Voltage:
-
AC 85V-240V 110V 220V 60HZ/50HZ
-
Controller working frequency:
-
433.92MHZ
-
Controller Maximum power:
-
<1000W
-
Controller Receiving sensitivity:
-
-108dBM
-
wireless switch battery:
-
CR2032 Alkaline Battery ( Not Included Battery)
-
wireless switch Coding method:
-
Learning Code EV 1527
|
rofessional wireless SWITCH supplier, we have various styles, 1 gang 2 gang 3 gang white black gold
rofessional wireless doorbell supplier, we have various styles, various plugs (US, EU, UK, AU, PLUG), support customization, welcome to consult
|
|
1, working voltage: DC 3V
2, working frequency: 433.92MHZ
3. Transmitting power: <10mW
4. Remote control distance: <50 meters (indoor distance)
5, working method: wireless remote control
6, coding method: learning code
7, modulation method: ASK
8, working temperature: -10 deg C ~ +70 deg C
9, size: 86 * 86 *15 (mm)
10. use 1PC CR2032 Alkaline Battery ( Not Included Battery),The service life is about 12 months. Life and frequency of use are related. Time may be longer |
|
1. Press and hold the controller for 3 seconds to enter the code matching mode (the code indicator light flashes 5 times).
At this time, press the wireless switch 2 times and wait for 2 seconds. The code is successful (the default is always on);
|
|
1.One controller can be equipped with 15 switches, one switch can be equipped with many controllers
2. Do not operate with power. Turn off the power supply and operate it. If the test is confirmed to be correct, use it under the guidance of a professional electrician.
3. When the voltage of the remote control is insufficient, please change the battery in time (the remote control distance becomes closer when the remote control battery voltage is insufficient).
4. When using wireless electronic products, care should be taken to avoid metal masks, large electronic devices, electromagnetic fields, etc., which have strong interference sources, to avoid remote control and short receiving distance or to work normally.
5. Do not use this electronic product abnormally. Abnormal use will reduce product performance and longevity. In severe cases, damage to the product will also pose a safety hazard.
|
Tip:
-
This switch can be freely combined (1x1 1x2 2x1 2x2 2x3 and other specifications), the price of each specification is different
-
each model price is not the same, European regulations, US regulations, British regulations are not the same. The more orders, the cheaper the price
Shipping:
-Please pay more attention to your order address which MUST MATCH your shipping address. (If you’re from Russia, Please leave your full name. It is very important)
-Shipping will be worldwide via ePacket/China Post Air Mail/DHL/TNT/EMS.
- If you buy more than one product, we can include battery transport
-Please check items when delivered, if damaged, please kindly accept it and contact us immediately. We will make a confirmation and give you a solution.
Warranty :
- In order to ensure the quality, the product is 100% tested, you can buy with confidence
-1 years manufacture warranty;
-Defective problem should be submitted within 10 business days after product is delivered;
-Shipping damage should be submitted within 7 business days after product is delivered.
-
We can provide CE, FCC and other certifications, you can consult customer service, quality is guaranteed. Selling at ease
Contact us:
-If you want to place a large order for wholesale, please feel free to contact us.
Feedback:
-Any feedback from you will be much appreciated. If you’re satisfied with our service or products, please give us 5 stars. -If you have any questions, please also contact with us, and we will offer help to you sooner.
Please Note:
-Import duties, taxes and charges are not included in shipping cost.
-Buyers bear all responsibility for all extra charges incurred (if any).
-For our customers from Brazi /India: if you choose any fast delivery(EMS/DHL), please leave your CPF number/ID Card document copy so that ensure our delivery normally.
