Quick Details
-
Weight (KG):
-
700 kg
-
Type:
-
Manual Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Capacity:
-
1.5 ton
-
Color:
-
Green
-
Size:
-
1810*850*2120 mm
-
Turning Radius:
-
1550 mm
-
Model:
-
KLD15D
-
Brand:
-
Samcy
-
Lifting Height:
-
1600-3000 mm
Quick Details
-
Warranty:
-
2 years
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
samcy
-
Weight (KG):
-
700 kg
-
Type:
-
Manual Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Capacity:
-
1.5 ton
-
Color:
-
Green
-
Size:
-
1810*850*2120 mm
-
Turning Radius:
-
1550 mm
-
Model:
-
KLD15D
-
Brand:
-
Samcy
-
Lifting Height:
-
1600-3000 mm
| Model | KLD15D | |||
| Performanc | Maximum load capacity | kg | 1500 | |
| load center | Q | mm | 600 | |
| Weight (with battery) | kg | ~700 | ||
| Maximum lifting height | H | mm | 1600/2000/2500/3000/3300 | |
| Travel speed (without load) | km/h | 4.5 | ||
| Travel speed (with load) | km/h | 3.5 | ||
| Lifting speed (without load) | mm/s | 140 | ||
| Lifting speed (with load) | mm/s | 135 | ||
| Lowered speed (without load) | mm/s | 150 | ||
| Lowered speed (with load) | mm/s | 155 | ||
| Ascend slope ability (without load ) | % | 7 | ||
| Ascend slope ability (with load ) | % | 3 | ||
| Overall length of frame | L | mm | 1810 | |
| Dimensions | Overall width of frame | B | mm | 850 |
| Mast lowered height | H1 | mm | 2120/1610/1835/2085/2235 | |
| Max height(mast lifted with backrest | H4 | mm | 2165/2670/3010/3510/3810 | |
| Wheelbase | Y | mm | 1340 | |
| Fork length | mm | 1150 | ||
| Fork outside width | B1 | mm | 680 | |
| Fork inside width | B2 | mm | 340 | |
| Fork thickness | mm | 65 | ||
| Min intersecting aisle width | mm | 2150 | ||
| Min frounf height | mm | 15 | ||
| Fork lowered height | S | mm | 90 | |
| Minimum turning radius | Wa | mm | 1550 | |
| Tire | Front wheel | mm | 85*70 | |
| Drive wheel | mm | 210*70 | ||
| Caster wheel | mm | 130*55 | ||
| Wheel material | polyurethane | |||
| Electrical components | Drive motor type | DC series motor | ||
| Rated output | kw | 0.75 | ||
| Hoist motor type | DC series motor | |||
| Rated output | kw | 2.2 | ||
| battery | Voltage | V | 24 | |
| Capacity | AH | 100 | ||
| Weight | kg | 35*2 | ||
| Size Chart (cm) | |||
| Capacity | 1.5 ton | ||
| size | 1810*850*2120 mm | ||
| Other Size could be Customized | |||
| Trade Terms | EXW, FOB, CFR, CIF or others |
| MOQ | 1 Set |
| Port | Shanghai Port, Ningbo Port or others |
| Shipment | Ocean or Air transportation, International Express |
| Payment Terms | LC D/A D/P T/T Western Union Money Gram |
| Payment Condition | 30% before Prodution, 70% after Delivery Upon BL |
| Supply Capacity | 10,000 Sets per Year |
| Delivery Time | 40 days after confirming the order |
| Service | OEM/ODM |
