Quick Details
-
Rolling thinckness:
-
0.3-0.8mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hrf
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
5m*1.3m*1.3m-15m*1.3m*1.4m
-
Weight:
-
30000 kg
-
Keywords:
-
U/Z/C light steel keel purlin roll forming machine
-
kerwords1:
-
Profile Roll Forming Production Line
-
Roller material:
-
Cr12
-
main machine power:
-
30kw
-
Material thickness:
-
1-3mm
-
shaft diameter:
-
80mm
-
way of cutting:
-
hydraulic mould cutting
-
hydraulic pressure:
-
11kw
-
machine weight:
-
15T
-
name:
-
c z purlin roll forming machine
Quick Details
-
Type:
-
Tile Forming Machine
-
Tile Type:
-
Cement
-
Production Capacity:
-
30 m/min
-
Rolling thinckness:
-
0.3-0.8mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hrf
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
5m*1.3m*1.3m-15m*1.3m*1.4m
-
Weight:
-
30000 kg
-
Keywords:
-
U/Z/C light steel keel purlin roll forming machine
-
kerwords1:
-
Profile Roll Forming Production Line
-
Roller material:
-
Cr12
-
main machine power:
-
30kw
-
Material thickness:
-
1-3mm
-
shaft diameter:
-
80mm
-
way of cutting:
-
hydraulic mould cutting
-
hydraulic pressure:
-
11kw
-
machine weight:
-
15T
-
name:
-
c z purlin roll forming machine
|
NO
|
ITEM
|
|
|
|
PARAMETER
|
|
|
REMARK
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
1.
|
Suitable material
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
CR/HR coil,G350Mpa
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
. 2
|
Finished purlin dimension
|
|
|
|
1)C/Z purlin width: 80-300mm automatic adjustment
2) C/Z purlin flange height:40-100mm automatic adjustment 3)Lip size:15-20mm 4) Thickness: 1.5-3.2mm |
|
|
|
|||||
|
3.
|
Roll Forming structure
|
|
|
|
Casting stands structure with 18 nos + series of vertical rollers
|
|
|
Casting stands
|
|||||
|
4.
|
Main forming machine motor power(kw)
|
|
|
|
18.5kw
|
|
|
Siemens motor made in china
|
|||||
|
5.
|
9 rolls Leveling motor( 4+5 rolls)
|
|
|
|
5.5kw
|
|
|
motor,made in china
|
|||||
|
6.
|
Hydraulic station power(kw) for main
|
|
|
|
11kw
|
|
|
Motor made in china
|
|||||
|
|
forming machine
|
|
|
|
|
|
|
|
|||||
|
7.
|
Motors for the height adjustment
|
|
|
|
1.5kw( 2-0.75kw)
|
|
|
Motor made in china
|
|||||
|
8
|
Motor for purlin width adjustment
|
|
|
|
1-1.5kw
|
|
|
Motor made in china
|
|||||
|
9.
|
Hydraulic station for main hydraulic decoiler
|
|
|
|
3kw
|
|
|
motor,made in china
|
|||||
|
10
|
Total power(kw)
|
|
|
|
About 51kw
|
|
|
|
|||||
|
11
|
Power supply requirement
|
|
|
|
380V,50Hz,3Ph
|
|
|
|
|||||
|
12
|
Machine dimension(LxWxH,m)
|
|
|
|
15mx2.5mx1.6m
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|||||
|
13
|
Machine color
|
|
|
|
Blue with yellow color combination
|
|
|
|
|||||
FAQ
1.Can one machine only produce one size?
Not exactly, it depends on the machine.
2. Do you have after-sales support?
Yes, we are happy to give advice and also have skilled technicians available to maintain the machine if needed.
3. How to visit your company?
We can pick you up from Shanghai or Hangzhou airport. Or railway station Shaoxing North. 4. What can you do if the machine is broken?
Our machine's warranty period is 12months. if the broken parts can't repair, we can send the new parts to replace the broken parts, but you need to pay the express cost by yourself. if after the warranty period, we can through negotiation for solving the problems, and we supply the technical support for the whole life of the equipment.
5.Can you be responsible for transport?
Yes, please tell us the destination port or address. we have rich experience in transport. 6. 6.You are a trade company or factory?
We are a Manufacturer.
7. Why your price is higher than others?
As we persist on that each factory should put quality in the first place. We spend time and money on developing how to make machines much more automatic, accurate, and high quality. We can make sure that our machine could use more than 20 years without any problem.
8. Do you have overseas engineers?
Yes, we not only provide overseas engineers but also provide technical training.
9. Do you provide customized?
Sure, we can design the equipment according to the data of the structural section you provide. We are a professional sheet metal forming machine designer and manufacturer.
