Quick Details
-
Dimension(L*W*H):
-
1270*550*1090mm
-
Weight (KG):
-
500 kg
-
Color:
-
Customized Color
-
Name:
-
Street Road Sweeper
-
Brand:
-
PLSON
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
PLSON
-
Power:
-
1050W
-
Dimension(L*W*H):
-
1270*550*1090mm
-
Weight (KG):
-
500 kg
-
Color:
-
Customized Color
-
Name:
-
Street Road Sweeper
-
Brand:
-
PLSON
Products Description
|
No.
|
Item Name
|
Parameters
|
|
1
|
Sweeping width（mm）
|
1900
|
|
2
|
Max. area performance（m2/h）
|
16000
|
|
3
|
Sweeping efficiency （%）
|
95
|
|
4
|
Effective load（kg）
|
400
|
|
5
|
Sweep speed（km/h）
|
0-10
|
|
6
|
Drive speed （km/h）
|
0-16
|
|
7
|
Hill climbing ability（%）
|
20
|
|
8
|
Min. turning radius(mm)
|
2000
|
|
9
|
Drive Model
|
4×4 wheel drive
|
|
10
|
Wheel base （mm）
|
1210
|
|
11
|
Drive methods
|
Hydrostatic transmission stepless variable speed
|
|
12
|
Garbage bin lifting height (m)
|
1.3
|
|
13
|
Inclined lift angle（°）
|
60
|
|
14
|
Dust bin capacity（L）
|
500L / 240L
|
|
15
|
Water Tank capacity（L）
|
≥140
|
|
16
|
Fuel tank capacity (L)
|
20
|
|
|
fuel consumption (L/h)
|
3.5
|
|
17
|
Sweep brush diameter (mm)
|
Φ650
|
|
|
Sucker diameter (mm)
|
Φ130
|
|
|
Nozzle diameter (mm)
|
Φ340
|
|
|
Lengthen of the Sucker (m)
|
5
|
|
|
Brush Tray diameter
|
φ420
|
|
18
|
Air conditioning evaporator assembly(w)
|
Overhead air conditioner and heater 800
|
|
19
|
Max. Total Weight (kg)
|
1800
|
|
|
Vehicle Weight (kg)
|
1400
|
|
20
|
Dimension(LxWxH) (mm)
|
3300*1160*2200
|
|
21
Engine Parameter |
Brand
|
Perkins, England
|
|
|
Engine Model
|
403D-11
|
|
|
Engine Type
|
In-line three cylinder, four stroke, water cooling, direct injection, diesel engine
|
|
|
Rated power / speed
（kw/rpm） |
21/3400
|
|
|
Engine working speed（rpm）
|
2000(general)-2800(enhance)rpm
|
|
|
Fuel type
|
0# light diesel oil
|
|
22
|
Engine power（kw）
|
21
|
|
23
|
Snow cleaning width（m）
|
1.2
|
