Rating: 10A 125VAC;6A 250VAC
Contact Resistance: 35mΩ max
Insulation Resistance :500VDC 100MΩ min
Dielectric Strength: 1500VAC,1 Minute
Operating Temperature: -25℃~+85℃
Electrical Life: >=10000 Cycles
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
KCD1-8-101
-
Max. Current:
-
10A
-
Mechanical Life:
-
100,000 cycles
-
Item number:
-
Round Rocker Switch
-
Lamp Voltage:
-
12V/24V/220V
-
Button Color:
-
Black with ON OFF
-
Function:
-
ON-OFF
-
Rating:
-
10A 125/250VAC
-
contact Resistance:
-
30 mΩ max
-
Insulation Resistance:
-
500 VDC 100MΩ
-
Dielectric Strength:
-
1500VAC,1minuute
-
Electric life:
-
100,000 cycles
-
Approved:
-
CE,CQC
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Daiertek
-
Model Number:
-
KCD1-8-101
-
Max. Current:
-
10A
-
Mechanical Life:
-
100,000 cycles
-
Item number:
-
Round Rocker Switch
-
Lamp Voltage:
-
12V/24V/220V
-
Button Color:
-
Black with ON OFF
-
Function:
-
ON-OFF
-
Rating:
-
10A 125/250VAC
-
contact Resistance:
-
30 mΩ max
-
Insulation Resistance:
-
500 VDC 100MΩ
-
Dielectric Strength:
-
1500VAC,1minuute
-
Electric life:
-
100,000 cycles
-
Approved:
-
CE,CQC
PRODUCT DESCRIPTION
|
Product Name
|
Round Rocker Switch 12V ON Off Switch 12 Volt DC Circle Toggle Switch 2 Pin SPST 6A/250V 10A/125V AC 20MM Mini Rocker Switch
|
|
Rating
|
6A 250VAC;10A 125VAC
|
|
Funtion
|
ON-OFF
|
|
Buton Color Avaliable
|
Transapent R,BL,Y,G
|
|
Lamp Voltage Avaliable
|
12/24/220V
|
|
Terminal Avaliable
|
Copper plated Silver
|
PRODUCT DETAILS
KCD1 Series Rocker Switch
Product function
We have single pass, double pass, single pass spacing ≥ 3mm, double pass ≥ 3mm, double pass without pause, double pass with pause
and single pass with reset,choose our products you like~
and single pass with reset,choose our products you like~
SPST Rocker Switch
It's a SPST 3 Pin ON/OFF Rocker Switch, Single Pole Single Throw design, and T85 Temperature Degree(-25C to +85C).
ON OFF Stamping
This switch is ON/OFF stamping,wich makes it easier to
identify its status comparing with "- O" stamping.
