Quick Details
-
overall dimentions:
-
300/275/100mm
-
voltage range:
-
250~450V
-
Rated current:
-
230A
-
Peak current:
-
450A
-
Protection grade:
-
IP67
-
motor cooling method:
-
54.5kg
-
Rated power:
-
45kw
Quick Details
-
Voltage:
-
50~650V
-
Brand:
-
GOLDGUN
-
Weight:
-
45kg
-
overall dimentions:
-
300/275/100mm
-
voltage range:
-
250~450V
-
Rated current:
-
230A
-
Peak current:
-
450A
-
Protection grade:
-
IP67
-
motor cooling method:
-
54.5kg
-
Rated power:
-
45kw
Product Description
Product Paramenters
|
Product model
|
TZ180XS015-1
|
|
|
|
Rated voltage (VDC)
|
292
|
Cooling method
|
Water cooling
|
|
Rated power (kW)
|
22
|
Back EMF (Vpeak)
|
503v@9700rpm
|
|
Rated torque(Nm)
|
70
|
Peak power(KW)
|
57
|
|
Rated speed (rpm)
|
3000
|
Peak torque (Nm)
|
150
|
|
Insulation class
|
H
|
Maximum speed (rpm)
|
9700
|
|
Dimensions (mm)
|
φ221*L277
|
Protection level
|
IP67
|
|
Weight (kg)
|
34kg
|
Peak current (Arms)
|
230
|
|
Product model
|
TZ180XS015-2
|
|
|
|
Rated voltage (VDC)
|
336
|
Cooling method
|
Water cooling
|
|
Rated power (kW)
|
18
|
Back EMF (Vpeak)
|
540@1000rpm
|
|
Rated torque (Nm)
|
60
|
Peak power (kW)
|
60
|
|
Rated speed (rpm)
|
2850
|
Peak torque (Nm)
|
145
|
|
Insulation class
|
H
|
Maximum speed (rpm)
|
9000
|
|
Dimensions (mm)
|
φ210*L293
|
Protection level
|
IP67
|
|
Weight (kg)
|
34kg
|
Peak current (Arms)
|
200
|
